Mountainite

KNa2Ca2[Si8O19(OH)] · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mtn
Discovered
1957
Also known as
  • Mountainiet

Where it forms, where it's found

Geological setting

Kimberlite pipe

Type locality
Bultfontein Mine
  1. KEM JV Mine (Kimberley Ekapa Mining Joint Venture mine
  2. Kimberley Underground mine)
  3. Kimberley
  4. Sol Plaatje Local Municipality
  5. Frances Baard District Municipality
  6. Northern Cape
  7. South Africa

-28.7682°, 24.7921°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
white
Streak
white
Cleavage
Poor/Indistinct

one doubtful in prism zone.

Density
2.36 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 78 – 80°
Refractive index
1.5 – 1.519
Surface relief
Moderate
Principal indices
nα 1.500 – 1.504 · nβ 1.505 – 1.510 · nγ 1.513 – 1.519
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#12
Cell parameters
a = 13.704(2) Å · b = 6.5760(10) Å · c = 13.751(2) Å
Cell angles
β = 105.752(10) °
Ratio a:b:c
1 : 0.480 : 1.003
Unit cell volume
1192.7 ų
Z
2
Morphology

As matted laths and fibers, elongated along [010], forming small rosettes, to 2 mm.

Type-locality form

silky white fibers

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
50.79%
14SiSiliconSilicon828.085224.680
27.43%
20CaCalciumCalcium240.07880.156
9.79%
11NaSodiumSodium222.99045.980
5.62%
19KPotassiumPotassium139.09839.098
4.77%
1HHydrogenHydrogen131.00813.104
1.60%
Total818.992100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mg
  • C

Synonyms

  • Mountainiet

In other languages

German
Mountainit
Italian
mountainite

Classification

Strunz
10th ed.

9.GG.10

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GGUnclassified zeolitesGroup
  • 9.GG.10MountainiteSpecies
Dana
8th ed.

77.02.03.01

  • 77Tectosilicates ZeolitesClass
  • 77.02Zeolite group - related speciesType
  • 77.02.03— unnamed intermediate level —Group
  • 77.02.03.01MountainiteSpecies
CIM

14.6.6

  • 14Silicates not Containing AluminumClass
  • 14.6Silicates of Ca with alkali or Mg or bothGroup
  • 14.6.6MountainiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1957Gard, J. A., Taylor, H. F. W., Chalmers, R. A. (1957) An investigation of two new minerals: rhodesite and mountainite. Mineralogical Magazine and Journal of the Mineralogical Society, 31 (239). 611-623 doi:10.1180/minmag.1957.31.239.02DOI: 10.1180/minmag.1957.31.239.02
  2. 1958Fleischer, M. (1958) New mineral names. American Mineralogist, 43, 623-626.
  3. 1973Bussen, I.V., Latysheva, L.G., Men'shikov, Y.P., Mer'kov, A.N., Romanova, T.S., Sakharov, A.S. (1973) First find of mountainite in the Soviet Union. Doklady Akademii Nauk SSSR: 210: 674-677. (in Russian)
  4. 2001(2001) Mountainite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2009Zubkova, Natalia V., Pekov, Igor V., Pushcharovsky, Dmitry Yu., Chukanov, Nikita V. (2009) The crystal structure and refined formula of mountainite, KNa2Ca2[Si8O19(OH)] · 6 H2O. Zeitschrift für Kristallographie, 224 (8). 389-396 doi:10.1524/zkri.2009.1159DOI: 10.1524/zkri.2009.1159
