Otavite

Cd(CO3)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ota
Discovered
1906

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

27recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Translucent
Colour
White to yellow-brown or reddish

yellowish brown to reddish brown if impure

Streak
White
Cleavage
Imperfect/Fair

On (1011)

Density
4.96 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.605 – 1.83
Surface relief
High
Principal indices
nω 1.830 · nε 1.605
Pleochroism
Non-pleochroic
Notes

colorless in thin section

Michel-Lévy diagramhighlighted lineδ = 0.2250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2250 nm5th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2250 nm
Order5th order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3c
Cell parameters
a = 4.93 Å · c = 16.27 Å
Z
6
Morphology

Crusts of minute rhombohedral crystals, <f>(1011)</f>.

Twinning

observed

Epitaxy

Otavite oriented growths on smithsonite (Tsumeb).

Comment

synthetic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
48CdCadmiumCadmium1112.414112.414
65.20%
8OOxygenOxygen315.99947.997
27.84%
6CCarbonCarbon112.01112.011
6.96%
Total172.422100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
Otavite
German
Otavit
Spanish
Otavita
Italian
Otavite
Japanese
菱カドミウム鉱
Russian
Отавит

Classification

Strunz
10th ed.

5.AB.05

  • 5CarbonatesClass
  • 5.ACarbonates without additional anions, without H2ODivision
  • 5.ABAlkali-earth (and other M2+) carbonatesGroup
  • 5.AB.05OtaviteSpecies
Dana
8th ed.

14.01.01.07

  • 14Anhydrous Normal CarbonatesClass
  • 14.01A(XO3)Type
  • 14.01.01Calcite Group (Trigonal: R-3c)Group
  • 14.01.01.07OtaviteSpecies
CIM

11.6.10

  • 11CarbonatesClass
  • 11.6Carbonates of Zn and CdGroup
  • 11.6.10OtaviteSpecies

Group, growth & confusion

In the same group
7 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1897de Schulten (1897) Bulletin de la Société française de Minéralogie: 20: 196.
  2. 1906Schneider, O. (1906) Vorläufige Notiz über einige sekundäre Minerlien von Otavi (Deutsch Süd-West-Afrika), darunter ein neues Cadmium-Mineral. Centralblatt für Mineralogie, Geologie und Paläontologie: 1906: 388-389.
  3. 1928Zachariasen, William Houlder (1928) Kristallstruktur von Verbindungen A2O3 und ABO3 [Crystal structure of compounds A2O3 and ABO3]. Det Norske Videnskaps-Akademi i Oslo Skrifter - I Mathematisk-Naturvidenskapelig Klasse Vol. 1928 (4). In commision with Jacob Dybwad
  4. 1941Ramdohr and Strunz (1941) Zentralblatt Mineralien: 97.
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
