Reinhardbraunsite

Ca5(SiO4)2(OH)2
IMA status
  • Approved
IMA symbol
Rbn
Discovered
1980
IMA approved
1980
Also known as
  • Calcio-chondrodite
  • Calcium Chondrodite
  • IMA1980-032
  • +1 more

Where it forms, where it's found

Geological setting

Occurs in xenoliths in scoria.

Type locality
Caspar quarry
  1. Ettringen
  2. Vordereifel
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.3525°, 7.2335°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale pink
Streak
White
Cleavage
Distinct/Good

On (001)

Fracture
Conchoidal
Density
2.85 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 44 – 50° · 2V calc = 54°
Refractive index
1.606 – 1.62
Surface relief
Moderate
Principal indices
nα 1.606 · nβ 1.617 · nγ 1.620
Dispersion
r > v, distinct
Extinction
Z = b; X ∧ c = 18(1)°.
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 11.45 Å · b = 5.05 Å · c = 8.84 Å
Cell angles
β = 108.91 °
Ratio a:b:c
1 : 0.441 : 0.772
Z
2
Twinning

Single and multiple twinning on (001), noted only in minute recrystallized grains.

Type-locality form

Anhedral to subhedral grains, up to 3 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium540.078200.390
47.88%
8OOxygenOxygen1015.999159.990
38.22%
14SiSiliconSilicon228.08556.170
13.42%
1HHydrogenHydrogen21.0082.016
0.48%
Total418.566100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • H2O
  • P

Synonyms

  • Calcio-chondrodite
  • Calcium Chondrodite
  • IMA1980-032
  • Reinhardbraunsiet

In other languages

German
IMA 1980-032 · Reinhardbraunsit
Italian
Reinhardbraunsite

Classification

Strunz
10th ed.

9.AF.45

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.45ReinhardbraunsiteSpecies
Dana
8th ed.

52.03.2b.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.03Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] coordination onlyType
  • 52.03.2b— unnamed intermediate level —Group
  • 52.03.2b.03ReinhardbraunsiteSpecies
CIM

14.2.7

  • 14Silicates not Containing AluminumClass
  • 14.2Silicates of CuGroup
  • 14.2.7ReinhardbraunsiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 1970Ganiev, R.M., Kharitonov, Y.A., Ilyukhin, V.V., Belov, N.V. (1970) The crystal structure of calcium chondrodite Ca5[SiO4]2(OH)2 = Ca(OH)2·2Ca2SiO4. Soviet Physics - Doklady, 14, 946-948.
  2. 1980Kuznetsova, T.P., Nevskii, N.N., Ilyukhin, V.V., Belov, N.V. (1980) Refinement of the crystal structure of calcium chondrodite Ca5[SiO4]2(OH)2=Ca(OH)2·2Ca2SiO4. Soviet Physics - Crystallography, 25, 91-92.
  3. 1983Dunn, P.J.; Grice, J.D.; Fleischer, M.; Pabst, A. (1983) New mineral names. American Mineralogist, 68 (9-10). 1038-1041
  4. 1983Hamm, H.M., Hentschel, G. (1983) Reinhardbraunsite, Ca5(SiO4)2(OH,F)2, a new mineral - the natural equivalent of synthetic "calcio-chondrodite". Neues Jahrbuch für Mineralogie, Monatshefte, 1983, 119-129.
  5. 1983Kirfel, A., Hamm, H. -M., Will, G. (1983) The crystal structure of reinhardbraunsite, Ca5(SiO4)2(OH,F)2, a new mineral of the calcio-chondrodite type. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 31 (1). 137-150 doi:10.1007/bf01084766DOI: 10.1007/bf01084766
