Kumtyubeite

Ca5(SiO4)2F2
IMA status
  • Approved
IMA symbol
Kty
Discovered
2006
IMA approved
2008
Also known as
  • IMA2008-045
  • Kumtyubeiet

Where it forms, where it's found

Geological setting

In contact-metasomatic rocks formed by interaction of carbonate xenoliths with subvolcanic magma and volcanites. The mineral occurs in spurrite-rondorfite-ellestadite zones of skarn.

Skarns, burned coal dumps.

Type locality
Xenolith no. 1
  1. Lakargi Mountain
  2. Upper Chegem volcanic caldera (Verkhnechegemskaya caldera)
  3. Chegemsky District
  4. Kabardino-Balkaria
  5. Russia

43.2000°, 43.1000°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light pink
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

distinct on (001)

Density
2.866 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 40 – 55° · 2V calc = 54.8°
Refractive index
1.594 – 1.608
Surface relief
Moderate
Principal indices
nα 1.594 · nβ 1.605 · nγ 1.608
Birefringence
0.014
Extinction
X^c = 15°, Z = b.
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 11.4340(19) Å · b = 5.0575(9) Å · c = 8.8657(16) Å
Cell angles
β = 108.860(12) °
Ratio a:b:c
1 : 0.442 : 0.775
Z
2
Morphology

Granular patches in skarn

Twinning

polysynthetic, twins on (001)

Type-locality form

Pale pink grains to 0.25 mm in 1 cm granular aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium540.078200.390
47.43%
8OOxygenOxygen815.999127.992
30.29%
14SiSiliconSilicon228.08556.170
13.29%
9FFluorineFluorine218.99837.996
8.99%
Total422.548100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2008-045
  • Kumtyubeiet

In other languages

German
IMA 2008-045 · Kumtyubeit
Italian
kumtyubeite

Classification

Strunz
10th ed.

9.AF.45

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.45KumtyubeiteSpecies
Dana
8th ed.

52.03.03.04

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.03Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] coordination onlyType
  • 52.03.03Chloritoid groupGroup
  • 52.03.03.04KumtyubeiteSpecies

Group, growth & confusion

In the same group
5 members

Literature, links & citation

Citations
  1. 2009Galuskina, I. O., Lazic, B., Armbruster, T., Galuskin, E. V., Gazeev, V. M., Zadov, A. E., Pertsev, N. N., Jezak, L., Wrzalik, R., Gurbanov, A. G. (2009) Kumtyubeite Ca5(SiO4)2F2 — A new calcium mineral of the humite group from Northern Caucasus, Kabardino-Balkaria, Russia. American Mineralogist, 94 (10) 1361-1370 doi:10.2138/am.2009.3256 DOI: 10.2138/am.2009.3256
  2. 2009Galuskin, Evgeny V., Gazeev, Viktor M., Lazic, Biljana, Armbruster, Thomas, Galuskina, Irina O., Zadov, Aleksander E., Pertsev, Nikolai N., Wrzalik, Roman, Dzierżanowski, Piotr, Gurbanov, Anatoly G., Bzowska, Grażyna (2009) Chegemite Ca7(SiO4)3(OH)2 a new humite-group calcium mineral from the Northern Caucasus, Kabardino-Balkaria, Russia. European Journal of Mineralogy, 21 (5) 1045-1059 doi:10.1127/0935-1221/2009/0021-1962 DOI: 10.1127/0935-1221/2009/0021-1962
  3. 2021(2021) Kumtyubeite. Handbook of Mineralogy. Mineralogical Society of America
