Chondrodite

Mg5(SiO4)2F2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Chn
Discovered
1817
Also known as
  • Brocchit
  • Brocchita
  • Brocchite
  • +7 more

Where it forms, where it's found

Geological setting

In marble, contact metamorphic rocks, carbonatites

Type locality
Skräbböle Quarry
  1. Pargas limestone mine
  2. Pargas
  3. Southwest Finland
  4. Finland

60.2931°, 22.2803°

256recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Yellow · Red or Brown.
Streak
White-gray, yellow
Tenacity
brittle
Cleavage
Poor/Indistinct

Indistinct on (100)

Density
3.16 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 64 – 90° · 2V calc = 76 – 78°
Refractive index
1.592 – 1.675
Surface relief
Moderate
Principal indices
nα 1.592 – 1.643 · nβ 1.602 – 1.655 · nγ 1.619 – 1.675
Birefringence
0.030
Pleochroism
Weak

X= colorless, very pale yellow, brownish yellow Y= colorless, yellow green Z= colorless, pale green

Dispersion
r > v weak to strong
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 7.84 Å · b = 4.73 Å · c = 10.25 Å
Cell angles
β = 109 °
Ratio a:b:c
1 : 0.603 : 1.307
Z
2
Morphology

Typically slightly flattened crystals, frequently rounded grains, massive

Twinning

On (001)

Parting
on (001)
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
37.24%
12MgMagnesiumMagnesium524.305121.525
35.36%
14SiSiliconSilicon228.08556.170
16.34%
9FFluorineFluorine218.99837.996
11.06%
Total343.683100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Mn

Synonyms

  • Brocchit
  • Brocchita
  • Brocchite
  • Brucite (of Gibbs)
  • Chondrodiet
  • Chondrodita
  • Condrodit
  • Prolectit
  • Prolectita
  • Prolectite

In other languages

French
Chondrodite
German
Chondrodit
Spanish
Brocchita · Condrodita · Prolectita
Italian
Chondrodite · Condrodite
Japanese
コンドロド石
Chinese
粒矽鎂石 · 粒硅镁石
Russian
хондродит

Classification

Strunz
10th ed.

9.AF.45

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.45ChondroditeSpecies
Dana
8th ed.

52.03.2b.02

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.03Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] coordination onlyType
  • 52.03.2b— unnamed intermediate level —Group
  • 52.03.2b.02ChondroditeSpecies
CIM

17.1.10

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.10ChondroditeSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1817d'Ohsson, Abraham Constantin Mouradgea (1817) Undersökning af någre mineralier. 3. En gul Sten ifrån Pargas [Examination of some minerals. 3. A yellow stone from Pargas]. Kungliga Svenska vetenskapsakademiens handlingar, S. 3 Vol. 5. 206-210
  2. 1822d’Ohsson, Abraham Constantin Mouradgea (1822) Analyses of Some Northern Minerals, Quarterly Journal of Science, Literature, and the Arts, 12: 329.
  3. 1822Seybert, Henry (1822) Analysis of the Maclureite or Fluosilicate of Magnesia, a New Mineral Species from New Jersey, American Journal of Science 5: 336-344.
  4. 1836Thomson, Thomas and Torrey, John (1836) Chemical Examination of Some Minerals, Chiefly from America (read November 5, 1827 by John Torrey), Annals of the Lyceum of Natural History of New-York, 3: 54-61.
  5. 1883Sjøgren, H. (1883): Chondrodit von Kavfeltorp, Zeitschrift für Kristallographie, Kristallgeometrie, Kristallphysik, Kristallchemie, Heft II, IX, pp 113-152.
