Steigerite

Al(VO4) · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sgr
Discovered
1935
Also known as
  • Steigeriet

Where it forms, where it's found

Geological setting

Nodular concretions of Corvusite in sandstone.

Type locality
Sullivan Brothers claims
  1. Gypsum Valley Mining District
  2. San Miguel County
  3. Colorado
  4. USA
7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Canary-yellow · greenish yellow · olive-green
Tenacity
fragile
Cleavage
Perfect

On (010), perfect; on (100), fair.

Density
2.52 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.72 – 1.752
Surface relief
High
Principal indices
nα 1.72 – 1.73 · nβ 1.73 – 1.734 · nγ 1.748 – 1.752
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0250
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]250 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation250 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 11.84 Å · b = 25 Å · c = 11.04 Å
Cell angles
β = 111.17 °
Ratio a:b:c
1 : 2.111 : 0.932
Z
24
Morphology

Cryptocrystalline fibrous, may be flat platy (010) Gumlike to compact massive, commonly as powdery coatings.

Type-locality form

Fracture cotings

Comment

Class is either 2/ or 2; space group is either P21/m or P21.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
57.15%
23VVanadiumVanadium150.94250.942
25.99%
13AlAluminiumAluminium126.98226.982
13.77%
1HHydrogenHydrogen61.0086.048
3.09%
Total195.965100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Steigeriet

In other languages

German
Steigerit
Italian
Steigerite

Classification

Strunz
10th ed.

8.CE.65

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.65SteigeriteSpecies
Dana
8th ed.

40.04.05.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.04(AB)5(XO4)2·xH2OType
  • 40.04.05— unnamed intermediate level —Group
  • 40.04.05.01SteigeriteSpecies
CIM

21.3.1

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.3Vanadates of Al, rare earths, Pb, V or BiGroup
  • 21.3.1SteigeriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1935Henderson, Edward P. (1935) Steigerite, a new vanadium mineral. American Mineralogist, 20 (11) 769-772
  2. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  3. 1963Ankinovich, E.A. (1963) New data on steigerite from southern Kazakhstan. Trudy Instituta Geologicheskikh Nauk Akademii Kazakh SSSR, 7, 207-217.
  4. 1964Fleischer, M. (1964) New Mineral Names. American Mineralogist, 49 (11-12) 1774-1778
  5. 1987Ankinovich, E.A., Kurmakaeva, F.A., Zazubina, I.S. (1987) Steigerite and vanalite from carbonaceous-siliceous vanadium-bearing formations of northwestern Kara-Tau (southern Kazakhstan). Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 116: 100–113 (in Russian with English abstract).
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Steigerite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/steigerite-3759},
  note      = {Accessed 2026-05-11}
}
