Tschörtnerite

Ca4(K,Ca,Sr,Ba)3Cu3Al12Si12O48(OH)8 · 20H2O
IMA status
  • Approved
IMA symbol
Tht
Also known as
  • IMA1995-051
  • Tschörtneriet

Where it forms, where it's found

Geological setting

Ca-rich xenolite in leucite-tephrite lava

Type locality
Caspar quarry
  1. Ettringen
  2. Vordereifel
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.3525°, 7.2335°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Light blue
Cleavage
None Observed
Fracture
Conchoidal
Density
2.1 g/cm³

Optical

Optical type
Isotropic
Surface relief
Moderate
Principal indices
n 1.504
UV response
None
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.504

Crystallography

Crystal system
Isometric
Space group
#224
Cell parameters
a = 31.62 Å
Unit cell volume
31614 ų
Z
16
Morphology

hexahedron faces

Twinning

None

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen7615.9991215.924
38.14%
56BaBariumBarium3137.327411.981
12.92%
14SiSiliconSilicon1228.085337.020
10.57%
13AlAluminiumAluminium1226.982323.784
10.15%
20CaCalciumCalcium740.078280.546
8.80%
38SrStrontiumStrontium387.620262.860
8.24%
29CuCopperCopper363.546190.638
5.98%
19KPotassiumPotassium339.098117.294
3.68%
1HHydrogenHydrogen481.00848.384
1.52%
Total3188.431100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1995-051
  • Tschörtneriet

In other languages

German
IMA 1995-051 · Tschörtnerit
Italian
IMA1995-051 · tschörtnerite

Classification

Strunz
10th ed.

9.GF.40

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GFOther Rare ZeolitesGroup
  • 9.GF.40TschörtneriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1998Effenberger, H., Giester, G., Krause, W., Bernhardt, H. J. (1998) Tschörtnerite, a copper-bearing zeolite from the Bellberg volcano, Eifel, Germany. American Mineralogist, 83 (5) 607-617 doi:10.2138/am-1998-5-620 DOI: 10.2138/am-1998-5-620
  2. 1999Mandarino, Joseph A. (1999) The Zeolite Group. The Mineralogical Record, 30 (1) 5-6
