Veszelyite

(Cu,Zn)2Zn(PO4)(OH)3 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Vsz
Discovered
1874
Also known as
  • Arakawaite
  • Kipushite (of Buttgenbach)
  • Veszelyiet

Where it forms, where it's found

Geological setting

Oxidised zones of base metal deposits.

Type locality
Ocna de Fier
  1. Caraş-Severin County
  2. Romania
19recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Green · blue · greenish blue · dark blue · greenish blue in transmitted light
Streak
Green to white
Cleavage
Distinct/Good

On (001) and (110).

Density
3.4 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 35 – 71° · 2V calc = 38 – 72°
Refractive index
1.618 – 1.695
Surface relief
High
Principal indices
nα 1.618 – 1.64 · nβ 1.622 – 1.658 · nγ 1.658 – 1.695
Pleochroism
Weak

Z = Blue X = Greenish blue

Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0475
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]475 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation475 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 9.8275 Å · b = 10.2244 Å · c = 7.5322 Å
Cell angles
β = 103.18 °
Ratio a:b:c
1 : 1.040 : 0.766
Z
4
Morphology

Crystals short prismatic (100), elongated [001]. Commonly pseudo-octahedral (100) and (011), modified by (001), (110), (111) and (121); also as granular aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc365.380196.140
38.82%
8OOxygenOxygen915.999143.991
28.50%
29CuCopperCopper263.546127.092
25.15%
15PPhosphorusPhosphorus130.97430.974
6.13%
1HHydrogenHydrogen71.0087.056
1.40%
Total505.253100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Arakawaite
  • Kipushite (of Buttgenbach)
  • Veszelyiet

In other languages

German
Veszelyit
Spanish
veszelyíta
Italian
Veszelyite
Japanese
ベゼライト · べゼリアイト · ベゼリ石 · 神岡石 · 荒川石

Classification

Strunz
10th ed.

8.DE.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DEWith only medium-sized cations, (OH, etc.):RO4 = 3:1Group
  • 8.DE.30VeszelyiteSpecies
Dana
8th ed.

42.02.03.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.02(AB)3(XO4)Zq·xH2OType
  • 42.02.03— unnamed intermediate level —Group
  • 42.02.03.01VeszelyiteSpecies
CIM

19.6.5

  • 19PhosphatesClass
  • 19.6Phosphates of ZnGroup
  • 19.6.5VeszelyiteSpecies

Group, growth & confusion

Often grow together
7 minerals

Literature, links & citation

Citations
  1. 1874Schrauf, A. (1874) Untersuchung eines neuen Mineral's, genannt Veszelyit. Anzeiger der Kaiserlichen Akademie der Wissenschaften: 11: 135-137.
  2. 1879Schrauf, A. (1879) Ueber Phosphorkupfererze. Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 4: 1-33 (31-33).
  3. 1920Mennell, F. P. (1920) Rare zinc-copper minerals from the Rhodesian Broken Hill mine, Northern Rhodesia. Mineralogical Magazine and Journal of the Mineralogical Society, 19 (90) 69-72 doi:10.1180/minmag.1920.019.90.03 DOI: 10.1180/minmag.1920.019.90.03
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1921Wakabayashi, Y., Komada, K. (1921) A phosphate of copper and zinc from the Arakawa mine. Journal of the Geological Society of Tokyo: 28: 191-211. (as Arakawaite)
