Vuagnatite

CaAlSiO4(OH)
IMA status
  • Approved
IMA symbol
Vgn
Discovered
1975
IMA approved
1975
Also known as
  • IMA1975-007
  • Vuagnatiet

Where it forms, where it's found

Geological setting

In rodingitized pegmatitic anorthositic gabbro dykes, cross-cutting harzburgite-serpentinite from an ophiolitic zone.

Type locality
Bögürtlencik Tepe
  1. Doganbaba
  2. Yeşilova District
  3. Burdur Province
  4. Turkey

37.6083°, 29.7417°

15recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colourless · light blue · tan · brown
Tenacity
brittle
Fracture
Conchoidal
Density
3.42 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 44° · 2V calc = 46°
Refractive index
1.701 – 1.727
Surface relief
High
Principal indices
nα 1.701 · nβ 1.724 · nγ 1.727
Pleochroism
Visible

X = colorless or yellowish brown; Y = Z = colorless.

Dispersion
Strong to very strong, r < v.
Extinction
X = c; Y = b; Z = a.
Notes

Absorption: X >> Y = Z.

Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 7.0538(4) Å · b = 8.5410(4) Å · c = 5.6839(3) Å
Ratio a:b:c
1 : 1.211 : 0.806
Z
4
Type-locality form

Anhedral and intimately intergrown with other calcium silicates and chlorite. As a replacement of plagioclase. Crystals from 0.03 to 0.5 mm in diameter. Frequently included by clinochlore, vesuvianite and hydrogrossular.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
45.41%
20CaCalciumCalcium140.07840.078
22.75%
14SiSiliconSilicon128.08528.085
15.95%
13AlAluminiumAluminium126.98226.982
15.32%
1HHydrogenHydrogen11.0081.008
0.57%
Total176.148100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • H2O
  • Fe
  • Ti

Synonyms

  • IMA1975-007
  • Vuagnatiet

In other languages

German
IMA 1975-007 · Vuagnatit
Italian
Vuagnatite
Chinese
羟硅铝钙石

Classification

Strunz
10th ed.

9.AG.60

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.60VuagnatiteSpecies
Dana
8th ed.

52.04.02.02

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.02Vuagnatite groupGroup
  • 52.04.02.02VuagnatiteSpecies
CIM

16.9.7

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.7VuagnatiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1976Sarp, Halil; Bertrand, Jean; Mc Near, Elizabeth (1976) Vuagnatite, CaAl(OH)SiO4, a new natural calcium aluminum nesosilicate. American Mineralogist, 61 (9-10). 825-830
  2. 1976Mc Near, Elizabeth; Vincent, Michael G.; Parthé, Erwin (1976) The crystal structure of vuagnatite, CaAl(OH)SiO4. American Mineralogist, 61 (9-10). 831-838
  3. 1977Erd, Richard C., Pabst, Adolf, Goff, Fraser, Rosenhahn, Leo (1977) Vuagnatite From California. The Mineralogical Record, 8 (6) 497-501
  4. 1979Craw, David; Landis, Charles A.; Kawachi, Yosuke (1979) Vuagnatite in New Zealand. New Zealand Journal of Geology and Geophysics, 22 (5). 627-629 doi:10.1080/00288306.1979.10424172DOI: 10.1080/00288306.1979.10424172
  5. 2001(2001) Vuagnatite. Handbook of Mineralogy. Mineralogical Society of America
