Yugawaralite

Ca(Si6Al2)O16 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Yug
Discovered
1952
Also known as
  • Yugawaraliet

Where it forms, where it's found

Geological setting

Andesite tuff metamorphosed by hot spring action.

Type locality
Yugawara Hot Spring
  1. Yugawara
  2. Ashigarashimo District
  3. Kanagawa Prefecture
  4. Japan

35.1533°, 139.0678°

32recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · pinkish
Streak
White
Tenacity
very brittle
Cleavage
Poor/Indistinct

(401), (100) distinct, (101) imperfect

Fracture
Conchoidal
Density
2.20 g/cm³

Optical

Optical type
Biaxial (+/-) · 2V measured = 48 – 89° · 2V calc = 58°
Refractive index
1.492 – 1.504
Surface relief
Low
Principal indices
nα 1.492 – 1.496 · nβ 1.497 – 1.499 · nγ 1.502 – 1.504
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
Pc
Cell parameters
a = 6.72(2) Å · b = 13.98(2) Å · c = 10.05(2) Å
Cell angles
β = 111.52 °
Ratio a:b:c
1 : 2.080 : 1.496
Z
2
Morphology

Crystals flat tabular parallel to (010). Showing (100), (010), (001), (110), (120), (011) and (_111).

Parting
(010)
Type-locality form

A network of veins with well devloped crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
54.18%
14SiSiliconSilicon628.085168.510
28.53%
13AlAluminiumAluminium226.98253.964
9.14%
20CaCalciumCalcium140.07840.078
6.79%
1HHydrogenHydrogen81.0088.064
1.36%
Total590.596100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • Na
  • K

Synonyms

  • Yugawaraliet

In other languages

German
Yugawaralith
Spanish
Yugawaralita
Italian
yugawaralite
Japanese
湯河原沸石
Russian
Югаваралит

Classification

Strunz
10th ed.

9.GB.15

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GBChains of single connected 4-membered ringsGroup
  • 9.GB.15YugawaraliteSpecies
Dana
8th ed.

77.01.07.02

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.07Brewsterite and related speciesGroup
  • 77.01.07.02YugawaraliteSpecies
CIM

16.9.24

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.24YugawaraliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1952Sakurai, K., Hayashi, A. (1952) “Yugawaralite”, a new zeolite. Science Reports of the Yokohama National University: 1: 69-77.
  2. 1953Fleischer, M. (1953) New mineral names. American Mineralogist: 38: 426-426.
  3. 1967Kerr, I. S., Williams, D. J. (1967) The crystal structure of yugawaralite. Zeitschrift für Kristallographie - Crystalline Materials, 125 (125) 220-225 doi:10.1524/zkri.1967.125.125.220DOI: 10.1524/zkri.1967.125.125.220
  4. 1969Leimer, H. W., Slaughter, M. (1969) The determination and refinement of the crystal structure of yugawaralite. Zeitschrift für Kristallographie - Crystalline Materials, 130 (1) 88-111 doi:10.1524/zkri.1969.130.1-6.88 DOI: 10.1524/zkri.1969.130.1-6.88
  5. 1971Eberlein, G. Donald, Erd, R. C., Weber, Florence, Beatty, and L. B. (1971) New occurrence of yugawaralite from the Chena Hot Springs area Alaska. American Mineralogist, 56 (9-10) 1699-1717
