Dickinsonite-(KMnNa)

K(NaMn)CaNa3AlMn13(PO4)12(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Dcn-KMnNa
Discovered
1878
IMA approved
2005
Also known as
  • Dickinsoniet-(KMnNa)
  • Dickinsonit
  • Dickinsonita
  • +2 more

Where it forms, where it's found

Geological setting

Pegmatite

Pegmatites

Type locality
Fillow Quarry
  1. Branchville
  2. Redding
  3. Fairfield County
  4. Connecticut
  5. USA

41.2678°, -73.4392°

31recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Green shades to dark green · yellowish green · brownish green · green in transmitted light.
Streak
Nearly white
Tenacity
very brittle
Cleavage
Perfect

On (001), perfect (almost micaceous).

Fracture
Irregular/Uneven
Density
3.38 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80 – 90° · 2V calc = 68 – 88°
Refractive index
1.648 – 1.671
Surface relief
High
Principal indices
nα 1.648 – 1.658 · nβ 1.655 – 1.662 · nγ 1.662 – 1.671
Pleochroism
Visible

X = b = Light olive-green Y = ^c ~ +15° = Lighter olive-green Z = Very light yellowish green

Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0135
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]135 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation135 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 24.94 Å · b = 10.13 Å · c = 16.72 Å
Cell angles
β = 105.6 °
Ratio a:b:c
1 : 0.406 : 0.670
Morphology

Crystals tabular (001). Commonly pseudo-rhombohedral in habit. Triangular striations on (001). Frequently foliated to micaceous; curved lamellar; radiated; stellated; and as disseminated scales.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen5015.999799.950
37.36%
25MnManganeseManganese1454.938769.132
35.93%
15PPhosphorusPhosphorus1230.974371.688
17.36%
11NaSodiumSodium422.99091.960
4.30%
20CaCalciumCalcium140.07840.078
1.87%
19KPotassiumPotassium139.09839.098
1.83%
13AlAluminiumAluminium126.98226.982
1.26%
1HHydrogenHydrogen21.0082.016
0.09%
Total2140.904100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dickinsoniet-(KMnNa)
  • Dickinsonit
  • Dickinsonita
  • Dickinsonite
  • IMA2005-048

In other languages

German
Dickinsonit-(KMnNa) · IMA 2005-048
Italian
Dickinsonite · Dickinsonite- · Dickinsonite-(KMnNa)
Chinese
磷碱锰石

Classification

Strunz
10th ed.

8.BF.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BFWith medium-sized and large cations, (OH, etc.):RO4< 0.5:1Group
  • 8.BF.05Dickinsonite-(KMnNa)Species
Dana
8th ed.

41.07.02.02

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.07(AB)7(XO4)4ZqType
  • 41.07.02— unnamed intermediate level —Group
  • 41.07.02.02Dickinsonite-(KMnNa)Species
CIM

19.12.33

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.33Dickinsonite-(KMnNa)Species

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. First Paper. American Journal of Science and Arts: 116: 33-46; 114-123. (as Dickinsonite).
  2. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. First Paper. American Journal of Science and Arts: 116: 33-46; 114-123.
  3. 1890Brush, G.J., Dana, E.S., Wells, H.L. (1890) On the mineral locality at Branchville, Connecticut: Fifth paper. American Journal of Science: 39: 201-216 (213).
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1930Berman, Harry, Gonyer, F. A. (1930) Pegmatite minerals of Poland, Maine. American Mineralogist, 15 (8) 375-387
