Ferrostrunzite

Fe2+Fe3+2(PO4)2(OH)2 · 6H2O
IMA status
  • Approved
IMA symbol
Fostz
Discovered
1983
IMA approved
1983
Also known as
  • Ferrostrunziet
  • IMA1983-003

Where it forms, where it's found

Geological setting

Phosphate replacements of marine shells in sedimentary marl.

Granite pegmatites; iron ore deposits

Type locality
Raccoon Creek
  1. Mullica Hill
  2. Harrison Township
  3. Gloucester County
  4. New Jersey
  5. USA

39.7339°, -75.2292°

20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Creamy yellow · pale yellow · tan to light brown
Streak
White.
Tenacity
brittle
Cleavage
Distinct/Good

Three cleavages. One parallel to crystal elongation, one nearly perpendicular to optic normal, one perpendicular to the acute bisectrix Bxa.

Fracture
Splintery
Density
2.50 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80° · 2V calc = 78°
Refractive index
1.628 – 1.723
Surface relief
High
Principal indices
nα 1.628 · nβ 1.682 · nγ 1.723
Birefringence
0.095
Pleochroism
Weak

X = yellow green, Z = orange

Dispersion
weak to distinct, asymmetric
Extinction
Z^c ~ 3°-8°
UV response
Not Fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0950
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]950 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation950 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.23 Å · b = 9.77 Å · c = 7.37 Å
Cell angles
α = 89.65 ° · β = 98.28 ° · γ = 117.26 °
Ratio a:b:c
1 : 0.955 : 0.720
Z
2
Type-locality form

Flattened prisms to 0.5 mm

Comment

Point Group: _1 or 1; Space Group: P_1 or P1

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
51.24%
26FeIronIron355.845167.535
33.54%
15PPhosphorusPhosphorus230.97461.948
12.40%
1HHydrogenHydrogen141.00814.112
2.82%
Total499.579100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ferrostrunziet
  • IMA1983-003

In other languages

German
Ferrostrunzit · IMA 1983-003
Italian
ferrostrunzite

Classification

Strunz
10th ed.

8.DC.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.25FerrostrunziteSpecies
Dana
8th ed.

42.11.09.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.09Strunzite GroupGroup
  • 42.11.09.02FerrostrunziteSpecies
CIM

19.13.9

  • 19PhosphatesClass
  • 19.13Phosphates of Fe aloneGroup
  • 19.13.9FerrostrunziteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
4 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1983Peacor, D.R., Dunn, P.J., Simmons, W.B. (1983) Ferrostrunzite, the ferrous iron analogue of strunzite from Mullica Hill, New Jersey. Neues Jahrbuch für Mineralogie, Monatshefte: 1983: 524-528.
  2. 1984Dunn, Pete J., Fleischer, Michael, Francis, Carl A., Langley, Richard H., Kissin, Stephen A., Shigley, Hames E., Vanko, David A., Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (7-8) 810-815
  3. 1984Simmons, William B., Coveney, Raymond M., Allen, Ashley V., Blankenship, James C. (1984) Hawleyite and Phosphate Minerals from Bethel Church, Indiana, Including a Second Occurrence for Ferrostrunzite. The Mineralogical Record, 15 (6) 351-357
  4. 1992van Tassel, R.; de Grave, Eddy (1992) Ferrostrunzite from Arnsberg, Sauerland, Germany. Neues Jahrbuch für Mineralogie - Monatshefte, 1992 (5). 207-212
  5. 2002Frost, R.L., Martens, W.N., Kloprogge, T., Williams, P.A. (2002) Vibrational spectroscopy of the basic manganese and ferric phosphate minerals: strunzite, ferrostrunzite and ferristrunzite. Neues Jahrbuch für Mineralogie, Monatshefte, 2002, 481-496.
