Gallite

CuGaS2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gal
Discovered
1958
Also known as
  • Galliet

Where it forms, where it's found

Geological setting

Base metal deposits with high gallium content.

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Grey
Streak
Greyish black
Density
4.2 g/cm³

Optical

Anisotropism
low
Internal reflections
None observed
Tropism
Anisotropic
Reflectance R%
(20.7)400, (19.9) 420, (19.4) 440, (18.8) 460, (18.5) 480, (18.1) 500, (17.9) 520, (17.7) 540, (17.5) 560, (17.4) 580, (17.2) 600, (17.1) 620, (17.0) 640, (16.9) 660, (16.8) 680, (16.6) 700
Reflected-light panel
18.0 %isotropic · single curve
Specimen sRGB 154, 108, 61
White reference100 % reflector under same lamp
Anisotropism
low
Internal reflections
None observed

Crystallography

Crystal system
Tetragonal
Space group
#141
Cell parameters
a = 5.360 Å · c = 10.49 Å
Z
4
Morphology

Massive, inclusions, exsolved lamellae to 2mm.

Twinning

Parallel to (112), (111)

Epitaxy

Gallite exsolves as lamellae || (100) and (111) of sphalerite, and in turn shows exsolution of sphalerite on (001) of gallite.

Type-locality form

Massive, as included grains and exsolution lamellae in other sulfides.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
31GaGalliumGallium169.72369.723
35.32%
16SSulfurSulfur232.06064.120
32.49%
29CuCopperCopper163.54663.546
32.19%
Total197.389100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Pb
  • Zn
  • Fe
  • Ge

Synonyms

  • Galliet

In other languages

German
Gallit
Spanish
Galita · Gallita
Italian
gallite
Russian
Галлит
Arabic
غاليت

Classification

Strunz
10th ed.

2.CB.10a

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CBWith Zn, Fe, Cu, Ag, etc.Group
  • 2.CB.10aGalliteSpecies
Dana
8th ed.

02.09.01.03

  • 02SulfidesClass
  • 02.09AmBnXp, with (m+n):p = 1:1Type
  • 02.09.01Chalcopyrite Group (Tetragonal: I-42d)Group
  • 02.09.01.03GalliteSpecies
CIM

3.5.18

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.5Sulphides etc. of Hg and TlGroup
  • 3.5.18GalliteSpecies

Group, growth & confusion

In the same group
6 members
Often grow together
8 minerals

Literature, links & citation

Citations
  1. 1958Strunz, H., Geier, B. H., Seeliger, E. (1958) Gallite, CuGaS2, das erste selbständige Galliummineral, und seine Verbreitung in den Erzen der Tsumeb- und Kipushi-Mine. Neues Jahrbuch für Mineralogie - Monatshefte, 1958. 241-264
  2. 1959Fleischer, M. (1959) New Mineral Names. American Mineralogist, 44 (7-8). 906-910
  3. 1969Springer, G. (1969) Microanalytical investigations into germanite, renierite, briartite, and gallite. Neues Jahrbuch für Mineralogie, Monatshefte 1969: 435-441.
  4. 2005(2005) Gallite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2005Ueno, T.; Nagasaki, K.; Horikawa, T.; Kawakami, M.; Kondo, K. (2005) Phase equilibria in the system Cu-Ga-S at 500° and 400°C. The Canadian Mineralogist, 43 (5). 1653-1661 doi:10.2113/gscanmin.43.5.1653 DOI: 10.2113/gscanmin.43.5.1653
