Geocronite

Pb14Sb6S23
IMA status
  • Approved
  • Grandfathered
IMA symbol
Geo
Discovered
1839
Also known as
  • Geochronite
  • Geocroniet
  • Geocronit
  • +8 more

Where it forms, where it's found

Geological setting

Hydrothermal veins

Type locality
Sala Silver Mine
  1. Sala
  2. Sala Municipality
  3. Västmanland County
  4. Sweden

59.9078°, 16.5789°

160recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Light lead gray to grayish
Streak
Light leadgray to grayish blue
Cleavage
Distinct/Good

Distinct on (011).

Fracture
Irregular/Uneven
Density
6.46 g/cm³

Optical

Pleochroism
Weak
Optical colour
Pure white
Anisotropism
Moderate
Tropism
Anisotropic
Reflectance R%
(40.5,45.3) 400, (40.4,45.0) 420, (40.0,44.4) 440, (39.7,43.9) 460, (39.5,43.6) 480, (39.3,43.2) 500, (39.1,42.8) 520, (38.8,42.3) 540, (38.6,41.9) 560, (38.3,41.5) 580, (38.0,41.1) 600, (37.7,40.6) 620, (37.2,40.1) 640, (36.5,39.4) 660, (35.9,38.8) 680, (35.1,38.2) 700
Reflected-light panel
38.4 %anisotropic · dual curve
Specimen sRGB 219, 155, 87
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Moderate
Reflected colour
Pure white

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.963 Å · b = 31.93 Å · c = 8.500 Å
Cell angles
β = 118.02(1) °
Ratio a:b:c
1 : 3.562 : 0.948
Z
2
Morphology

Tabular, massive, earthy. Crystals rare, but up to 8cm.

Twinning

Common on (001), lamellar.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead14207.2002900.800
66.40%
16SSulfurSulfur2332.060737.380
16.88%
51SbAntimonyAntimony6121.760730.560
16.72%
Total4368.740100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Geochronite
  • Geocroniet
  • Geocronit
  • Geokronite
  • Kilbreckanite
  • Kilbrickenit
  • Kilbrickenita
  • Kilbrickenite
  • Kilbrikenite
  • Schulzit
  • Schulzite

In other languages

French
geocronite
German
Geokronit
Spanish
geocronita
Italian
geocronite
Chinese
砷硫锑铅矿
Simplified Chinese
砷硫锑铅矿
Traditional Chinese
砷硫銻鉛礦

Classification

Strunz
10th ed.

2.JB.30a

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.30aGeocroniteSpecies
Dana
8th ed.

03.03.01.02

  • 03SulfosaltsClass
  • 03.033 <ø < 4Type
  • 03.03.01— unnamed intermediate level —Group
  • 03.03.01.02GeocroniteSpecies
CIM

5.6.22

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.22GeocroniteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
6 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1839Svanberg (1839) Ak. Stockholm, Handl.: 184.
  2. 1840Svanberg, L. F. (1840) Untersuchung des Geokronit und Hydrophit, zweier in Schweden vorkommenden neuen Mineralien. Annalen der Physik und Chemie, 127. 535-538 doi:10.1002/andp.18401271210DOI: 10.1002/andp.18401271210
  3. 1841Svanberg, L.F. (1841) Undersökning af geokronit och hydrofit, tvenne inom Sverige förekommande nya mineralier. Kongliga Svenska Vetenskaps-Akademiens Handlingar: 1839: 184-187.
  4. 1841Apjohn (1841), Proceedings of the Royal Irish Academy: 1: 469.
  5. 1847Hausmann (1847): 166.
