Gudmundite

FeSbS
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gu
Discovered
1928

Where it forms, where it's found

Geological setting

In calcite veins cutting skarn

Late stage hydrothermal mineral

Type locality
Gudmundstorp
  1. Sala Municipality
  2. Västmanland County
  3. Sweden

59.9357°, 16.6004°

208recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver white to steel gray
Tenacity
brittle
Density
6.72 g/cm³

Optical

Pleochroism
Visible

Pure white and pinkish white

Optical colour
Silver-white to steel-gray
Anisotropism
Strong - in yellow and red tints
Tropism
Anisotropic
Reflectance R%
(49.1,54.3) 400, (49.4,55.7) 420, (49.5,56.1) 440, (49.7,56.4) 460, (49.9,56.8) 480, (50.2,57.1) 500, (50.7,57.0) 520, (51.3,56.7) 540, (52.0,56.3) 560, (52.7,55.8) 580, (53.2,55.1) 600, (53.6,54.5) 620, (53.9,53.9) 640, (54.1,53.4) 660, (54.2,52.7) 680, (54.4,52.4) 700
Reflected-light panel
51.7 %anisotropic · dual curve
Specimen sRGB 255, 176, 95
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong - in yellow and red tints
Reflected colour
Silver-white to steel-gray

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 10.00 Å · b = 5.95 Å · c = 6.73 Å
Cell angles
β = 90 °
Ratio a:b:c
1 : 0.595 : 0.673
Z
8
Morphology

Tapered prisms

Twinning

On (101), penetration and contact, cruciform and butterfly shapes

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
58.07%
26FeIronIron155.84555.845
26.64%
16SSulfurSulfur132.06032.060
15.29%
Total209.665100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni

In other languages

French
Gudmundite
German
Gudmundit
Spanish
Gudmundita
Italian
Gudmundite

Classification

Strunz
10th ed.

2.EB.20

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EBM:S = 1:2, with Fe, Co, Ni, PGE, etc.Group
  • 2.EB.20GudmunditeSpecies
Dana
8th ed.

02.12.04.02

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.04Arsenopyrite Group (Monoclinic: P21/c (Pseudo-orthorhombic))Group
  • 02.12.04.02GudmunditeSpecies
CIM

3.9.13

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.9Sulphides etc. of FeGroup
  • 3.9.13GudmunditeSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
9 minerals

Literature, links & citation

Citations
  1. Zeitschrift für Kristallographie: A101: 290-316.
  2. 1928Foshag, W.F. (1928) New mineral names. American Mineralogist, 13 (12). 592-593
  3. 1939Buerger, M. J. (1939) The Crystal Structure of Gudmundite (FeSbS) and its Bearing on the Existence Field of the Arsenopyrite Structural Type. Zeitschrift für Kristallographie, 101 (1). 290-316 doi:10.1524/zkri.1939.101.1.290DOI: 10.1524/zkri.1939.101.1.290
  4. 1939Buerger, M.J. (1939) The crystal structure of gudmundite. American Mineralogist: 24: 183-184.
  5. 1941Sampson, Edward (1941) Notes on the occurrence of gudmundite. Economic Geology, 36 (2) 175-184 doi:10.2113/gsecongeo.36.2.175DOI: 10.2113/gsecongeo.36.2.175
