Hielscherite

Ca6Si2[(SO4)2(SO3)2(OH)12] · 22H2O
IMA status
  • Approved
IMA symbol
Hsc
IMA approved
2011
Also known as
  • Hielscheriet
  • IMA2011-037

Where it forms, where it's found

Geological setting

Alkalin basalt

Type locality
Graulay quarry
  1. Hillesheim
  2. Gerolstein
  3. Vulkaneifel
  4. Rhineland-Palatinate
  5. Germany

50.2764°, 6.6731°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless

crystal aggregates are white

Density
1.82 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.476 – 1.494
Surface relief
Low
Principal indices
nω 1.494 · nε 1.476
Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 11.1178(2) Å · c = 10.5381(2) Å
Morphology

Matted fibrous aggregates up to 1 cm across; Groups of acicular to prismatic hexagonal crystals up to 0.3×0.3×1.5 mm.

Type-locality form

in cavities

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4815.999767.952
61.47%
20CaCalciumCalcium640.078240.468
19.25%
16SSulfurSulfur432.060128.240
10.26%
1HHydrogenHydrogen561.00856.448
4.52%
14SiSiliconSilicon228.08556.170
4.50%
Total1249.278100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hielscheriet
  • IMA2011-037

In other languages

German
Hielscherit · IMA 2011-037
Italian
hielscherite

Classification

Strunz
10th ed.

7.DG.15

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DGWith large and medium-sized cations; with NO3, CO3, B(OH)4, SiO4 or IO3Group
  • 7.DG.15HielscheriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011, CNMNC Newsletter No. 10. Mineralogical Magazine, 75 (5) 2549-2561 doi:10.1180/minmag.2011.075.5.2549 DOI: 10.1180/minmag.2011.075.5.2549
  2. 2012Pekov, I. V., Chukanov, N. V., Britvin, S. N., Kabalov, Y. K., Göttlicher, J., Yapaskurt, V. O., Zadov, A. E., Krivovichev, S. V., Schüller, W., Ternes, B. (2012) The sulfite anion in ettringite-group minerals: a new mineral species hielscherite, Ca3Si(OH)6(SO4)(SO3)·11H2O, and the thaumasite–hielscherite solid-solution series. Mineralogical Magazine, 76 (5) 1133-1152 doi:10.1180/minmag.2012.076.5.06 DOI: 10.1180/minmag.2012.076.5.06
  3. 2015(2015) Hielscherite. Handbook of Mineralogy. Mineralogical Society of America
