Hiortdahlite

Na2Ca4(Ca0.5Zr0.5)Zr(Si2O7)2OF3
IMA status
  • Approved
IMA symbol
Hio
Discovered
1889
Also known as
  • Hiortdahliet
  • Hiortdahlite I

Where it forms, where it's found

35recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Greasy
Transparency
Translucent
Colour
Yellow · yellowish-brown · green
Tenacity
very brittle
Cleavage
Distinct/Good

Distinct on {110) and {1_10)

Density
3.25 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80° · 2V calc = 80 – 86°
Refractive index
1.639 – 1.671
Surface relief
High
Principal indices
nα 1.639 – 1.658 · nβ 1.643 – 1.664 · nγ 1.646 – 1.671
Pleochroism

X = nearly colorless, Y = bright yellow, Z = wine-yellow

Dispersion
r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 10.9517 Å · b = 10.31 Å · c = 7.29 Å
Cell angles
α = 90.32 ° · β = 109.03 ° · γ = 95.08 °
Ratio a:b:c
1 : 0.941 : 0.666
Z
4
Twinning

Polysynthetic twinning on (010) and (100)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
31.07%
20CaCalciumCalcium4.540.078180.351
23.35%
40ZrZirconiumZirconium1.591.224136.836
17.71%
14SiSiliconSilicon428.085112.340
14.54%
9FFluorineFluorine318.99856.994
7.38%
11NaSodiumSodium222.99045.980
5.95%
Total772.486100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • OH
  • Hf
  • Sn
  • Al
  • Y
  • TR
  • Fe
  • Nb
  • U
  • Mn
  • Mg
  • Sr
  • K

Synonyms

  • Hiortdahliet
  • Hiortdahlite I

In other languages

German
Hiortdahlit
Italian
Hiortdahlite
Chinese
希硅锆钠钙石
Russian
Йортдалит

Classification

Strunz
10th ed.

9.BE.17

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.17HiortdahliteSpecies
Dana
8th ed.

56.02.04.07

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.04Cuspidine - Wohlerite groupGroup
  • 56.02.04.07HiortdahliteSpecies
CIM

17.1.22

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.22HiortdahliteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1888Brøgger, W. C. (1888) Vorläufige Mittheilung über den "Hiortdahlit", ein neues Mineral von Arö, Norwegen [Preliminary communication on the "Hiortdahlite", a new mineral from Arö, Norway]. Nyt magazin for naturvidenskaberne [New magazine for the natural sciences], 31 (3). 232-239
  2. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  3. 1909Zambonini, F., Prior, G. T. (1909) On the identity of Guarinite and Hiortdahlite. Mineralogical Magazine and Journal of the Mineralogical Society, 15 (70) 247-259 doi:10.1180/minmag.1909.015.70.09 DOI: 10.1180/minmag.1909.015.70.09
  4. 1974Aarden, H. M., Gittins, J. (1974) Hiortdahlite from Kipawa River, Villedieu Township Temiscaming County, Québec, Canada. The Canadian Mineralogist, 12 (4) 241-247
  5. 1979Eggleton, R. A., Halford, G. E., Beams, S. D. (1979) Hiortdahlite from Jingera, New South Wales. Journal of the Geological Society of Australia, 26 (1) 81-85 doi:10.1080/00167617908729069DOI: 10.1080/00167617908729069
