Omphacite

(Ca,Na)(Mg,Fe,Al)Si2O6
IMA status
  • Approved
IMA symbol
Omp
Discovered
1815
Also known as
  • Diopsidjadeit
  • Diopsidjadeita
  • Diopsidjadeite
  • +8 more

Where it forms, where it's found

Type locality
Eclogite outcrops
  1. Weißenstein
  2. Stammbach
  3. Hof District
  4. Upper Franconia
  5. Bavaria
  6. Germany

50.1314°, 11.6853°

218recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Dark green
Streak
greenish white
Cleavage
Distinct/Good

Optical

Optical type
Biaxial (+) · 2V measured = 58 – 83° · 2V calc = 74 – 88°
Refractive index
1.662 – 1.723
Surface relief
High
Principal indices
nα 1.662 – 1.701 · nβ 1.67 – 1.712 · nγ 1.685 – 1.723
Dispersion
r > v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0225
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]225 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation225 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 9.66 Å · b = 8.81 Å · c = 5.22 Å
Cell angles
β = 106.56 °
Ratio a:b:c
1 : 0.912 : 0.540
Comment

Space group may be C2/c or P2/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
29.78%
14SiSiliconSilicon228.08556.170
17.43%
26FeIronIron155.84555.845
17.32%
20CaCalciumCalcium140.07840.078
12.43%
13AlAluminiumAluminium126.98226.982
8.37%
12MgMagnesiumMagnesium124.30524.305
7.54%
11NaSodiumSodium122.99022.990
7.13%
Total322.364100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Cr
  • Mn
  • K
  • H2O

Synonyms

  • Diopsidjadeit
  • Diopsidjadeita
  • Diopsidjadeite
  • Jadeite-Diopside
  • Mayait
  • Mayaita
  • Mexikanischer Jadeit
  • Omphacita
  • Omphazit
  • Tuxtlit
  • Tuxtlita

In other languages

French
Omphacite
German
Omphacit
Spanish
Onfacita
Italian
Omfacite
Portuguese
onfacite
Japanese
オンファス輝石
Arabic
أومفاسيت

Classification

Strunz
10th ed.

9.DA.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DAInosilicates with 2-periodic single chains, Si2O6; pyroxene familyGroup
  • 9.DA.20OmphaciteSpecies
Dana
8th ed.

65.01.3b.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.01Single-Width Unbranched Chains, W=1 with chains P=2Type
  • 65.01.3b— unnamed intermediate level —Group
  • 65.01.3b.01OmphaciteSpecies
CIM

16.24.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.24Aluminosilicates of Fe, Mg, Ca and alkalisGroup
  • 16.24.2OmphaciteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. Witzke, T, (undated) Omphacite. https://www.strahlen.org/tw/typloc/omphacit.html
  2. 1815Hoffmann, C. A. S. & Breithaupt, A. (1815) Omphazit. Handbuch der Mineralogie. Zweiten Bandes zweite Abtheilung.- Freiberg, bei Craz und Gerlach, 322 p. (p. 300-302)
  3. 1817Werner, Abraham Gottlob (1817) Letztes Mineral-System - Aus dessen Nachlasse auf oberbergamtliche Anordnung herausgegeben und mit Erläuterungen versehen.
  4. 1847BREITHAUPT, A. (1847): Vollständiges Handbuch der Mineralogie. 3. Band. Des speziellen Theiles zweite Abtheilung.- Dresden und Leipzig, Arnoldische Buchhandlung, 407-914 p. (p. 612)
  5. 1866BREITHAUPT, A. (1866): Mineralogische Studien.- Leipzig, Verlag von Arthur Felix, 122 p. (p. 112)
