Piemontite-(Sr)

CaSr(Al2Mn3+)[Si2O7][SiO4]O(OH)
IMA status
  • Approved
IMA symbol
Pmt-Sr
Discovered
1989
IMA approved
1989
Also known as
  • IMA1989-031
  • Piemontiet-(Sr)
  • Strontiopiemontit
  • +2 more

Where it forms, where it's found

Geological setting

Low-temperature metamorphic rocks.

Type locality
Molinello Mine
  1. Ne
  2. Genoa
  3. Liguria
  4. Italy

44.3453°, 9.4589°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark red
Streak
Purplish brown
Cleavage
Perfect

(001)

Density
3.65 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.763
Surface relief
High
Principal indices
nβ 1.763
Dispersion
very strong
Extinction
Y = b.

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.8942(1) Å · b = 5.6540(1) Å · c = 10.1928(2) Å
Cell angles
β = 115.100(1) °
Ratio a:b:c
1 : 0.636 : 1.146
Z
2
Morphology

Prismatic crystals, elongated parallel to [010].

Type-locality form

Small prismatic crystals, up to 0.5 mm, in veinlets about 3-4 mm thick, that cut black manganese ore.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
39.25%
38SrStrontiumStrontium187.62087.620
16.54%
14SiSiliconSilicon328.08584.255
15.90%
25MnManganeseManganese154.93854.938
10.37%
13AlAluminiumAluminium226.98253.964
10.19%
20CaCalciumCalcium140.07840.078
7.56%
1HHydrogenHydrogen11.0081.008
0.19%
Total529.850100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ti
  • Mg
  • H2O

Synonyms

  • IMA1989-031
  • Piemontiet-(Sr)
  • Strontiopiemontit
  • Strontiopiemontita
  • Strontiopiemontite

In other languages

German
IMA 1989-031 · Piemontit-(Sr)
Italian
Piemontite- · Piemontite-(Sr) · Stronziopiemontite

Classification

Strunz
10th ed.

9.BG.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.05Piemontite-(Sr)Species
Dana
8th ed.

58.02.1a.12

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.1a— unnamed intermediate level —Group
  • 58.02.1a.12Piemontite-(Sr)Species
CIM

16.16.25

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.25Piemontite-(Sr)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1990Bonazzi, Paola, Menchetti, Silvio, Palenzona, Andrea (1990) Strontiopiemontite, a new member of the epidote group, from Val Graveglia, Liguria, Italy. European Journal of Mineralogy, 2 (4) 519-523 doi:10.1127/ejm/2/4/0519 DOI: 10.1127/ejm/2/4/0519
  2. 2000AKASAKA, Masahide, ZHENG, Yuanyuan, SUZUKI, Yayoi (2000) Maximum strontium content of piemontite formed by hydrothermal synthesis. Journal of Mineralogical and Petrological Sciences, 95 (5) 84-94 doi:10.2465/jmps.95.84 DOI: 10.2465/jmps.95.84
  3. 2001(2001) Piemontite-(Sr). Handbook of Mineralogy. Mineralogical Society of America
  4. 2006Armbruster, Thomas, Bonazzi, Paola, Akasaka, Masahide, Bermanec, Vladimir, Chopin, Christian, Gieré, Reto, Heuss-Assbichler, Soraya, Liebscher, Axel, Menchetti, Silvio, Pan, Yuanming, Pasero, Marco (2006) Recommended nomenclature of epidote-group minerals. European Journal of Mineralogy, 18 (5) 551-567 doi:10.1127/0935-1221/2006/0018-0551DOI: 10.1127/0935-1221/2006/0018-0551
  5. 2010NAGASHIMA, Mariko, ARMBRUSTER, Thomas, AKASAKA, Masahide, MINAKAWA, Tetsuo (2010) Crystal chemistry of Mn2+-, Sr-rich and REE-bearing piemontite from the Kamisugai mine in the Sambagawa metamorphic belt, Shikoku, Japan. Journal of Mineralogical and Petrological Sciences, 105 (3) 142-150 doi:10.2465/jmps.090709 DOI: 10.2465/jmps.090709
