Piemontite

Ca2(Al2Mn3+)[Si2O7][SiO4]O(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pmt
Discovered
1758
Also known as
  • Epidote Manganèsifère
  • Piedmontit
  • Piedmontita
  • +2 more

Where it forms, where it's found

Geological setting

Greenschist to amphibolite grade regional metamorphism, metasomatised manganese deposits, low temperature hydrothermal veins.

Type locality
Praborna Mine
  1. Servette-Chuc mining complex
  2. Saint-Marcel
  3. Aosta Valley
  4. Italy

45.6794°, 7.4494°

221recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Red · red-violet · red-brown to reddish black
Streak
Reddish
Tenacity
brittle
Cleavage
Perfect

Perfect on (001) Poor on (100)

Fracture
Irregular/Uneven
Density
3.46 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 50 – 86° · 2V calc = 54 – 86°
Refractive index
1.725 – 1.832
Surface relief
High
Principal indices
nα 1.725 – 1.756 · nβ 1.73 – 1.789 · nγ 1.75 – 1.832
Pleochroism
Visible

X= light yellow, orange to pink Y= pale violet to deep lavender Z= pink to deep red

Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0505
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]505 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation505 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.878(10) Å · b = 5.692(5) Å · c = 10.201(10) Å
Cell angles
β = 115.25 °
Ratio a:b:c
1 : 0.641 : 1.149
Z
2
Morphology

Prismatic, bladed or acicular crystals.

Twinning

(100) uncommon, lamellar

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
43.12%
14SiSiliconSilicon328.08584.255
17.47%
20CaCalciumCalcium240.07880.156
16.62%
25MnManganeseManganese154.93854.938
11.39%
13AlAluminiumAluminium226.98253.964
11.19%
1HHydrogenHydrogen11.0081.008
0.21%
Total482.308100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ti
  • Na
  • K
  • H2O

Synonyms

  • Epidote Manganèsifère
  • Piedmontit
  • Piedmontita
  • Piedmontite
  • Piemontiet

In other languages

French
Epidote manganésifère · Piedmontite · Piémontite · Withamite
German
Mangan-Epidot · Manganepidot · Piemontit
Spanish
Piemontita
Italian
Piemontite
Japanese
紅簾石

Classification

Strunz
10th ed.

9.BG.05a

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.05aPiemontiteSpecies
Dana
8th ed.

58.02.1a.11

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.1a— unnamed intermediate level —Group
  • 58.02.1a.11PiemontiteSpecies
CIM

16.16.22

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.22PiemontiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1803Cordier, L. (1803) Analyse du Mineral connu sous le nom de Mine de Manganese violet du Piemont, faite au Labratoire del'Ecole de Mines. Journal des mines: 13(74): 135-142.
  2. 1853Kenngott, A. (1853) Piemontit. in Das Mohs’sche Mineralsystem, Verlag und Druck (Wien): 74-75.
  3. 1933Short, Allan M. (1933) A chemical and optical study of piedmontite from Shadow Lake, Madera Co., California. American Mineralogist, 18 (11) 493-500
  4. 1959Marmo, V., Neuvonen, K.J., Ojanperä, P. (1959) The piedmontites of piedmont (Italy), Kajlidongri (India), and Marampa (Sierra Leone). Bulletin de la Commission Géologique de Findlande: 184: 11-20.
  5. 1962(1962) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258) 260-263 doi:10.1180/minmag.1962.033.258.09 DOI: 10.1180/minmag.1962.033.258.09
