Hancockite

CaPb(Al2Fe3+)[Si2O7][SiO4]O(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hnc
Discovered
1899
Also known as
  • Epidot-(Pb)
  • Epidote-(Pb)
  • Hancockiet

Where it forms, where it's found

Geological setting

Metamorphosed stratiform zinc deposit.

Type locality
Franklin Mine
  1. Franklin
  2. Sussex County
  3. New Jersey
  4. USA

41.1158°, -74.5875°

8recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Dark brick-red (TL) · greenish-brown · yellow-brown

Optical

Optical type
Biaxial (-) · 2V measured = 50° · 2V calc = 88°
Refractive index
1.79 – 1.83
Surface relief
Very high
Principal indices
nα 1.79 · nβ 1.81 · nγ 1.83
Dispersion
r > v perceptible
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.9496(3) Å · b = 5.6474(2) Å · c = 10.2724(3) Å
Cell angles
β = 114.362(1) °
Ratio a:b:c
1 : 0.631 : 1.148
Z
2
Type-locality form

Massive and in cellular masses. Very small, lath-shaped crystals, up to 0.5 mm in length and 0.15 mm in width.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1315.999207.987
31.98%
82PbLeadLead1207.200207.200
31.86%
14SiSiliconSilicon328.08584.255
12.96%
26FeIronIron155.84555.845
8.59%
13AlAluminiumAluminium226.98253.964
8.30%
20CaCalciumCalcium140.07840.078
6.16%
1HHydrogenHydrogen11.0081.008
0.15%
Total650.337100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • Sr
  • Fe
  • Ti
  • Mn
  • Mg
  • Ba

Synonyms

  • Epidot-(Pb)
  • Epidote-(Pb)
  • Hancockiet

In other languages

German
Hancockit
Italian
Epidote-(Pb) · Epidoto-(Pb) · Hancockite
Chinese
铅黝帘石

Classification

Strunz
10th ed.

9.BG.05a

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.05aHancockiteSpecies
Dana
8th ed.

58.02.1a.08

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.1a— unnamed intermediate level —Group
  • 58.02.1a.08HancockiteSpecies
CIM

16.14.16

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.14Aluminosilicates of Ti, Zr, Sn and PbGroup
  • 16.14.16HancockiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1899Penfield, Samuel Lewis; Hyde, Warren Charles (1899) Some New Minerals from the Zinc Mines at Franklin, N. J., and Note Concerning the Chemical Composition of Ganomalite. American Journal Of Science, S. 3 Vol. 8. 339-353
  2. 1935Palache, Charles (1935) The minerals of Franklin and Sterling Hill, Sussex County, New Jersey. Professional Paper 180. US Geological Survey 135 pp. doi:10.3133/pp180 DOI: 10.3133/pp180
  3. 1971Dollase, W. A. (1971) Refinement of the crystal structures of epidote, allanite, and hancockite. American Mineralogist, 56 (3-4) 447-464
  4. 1972Frondel, Clifford (1972) The Minerals of Franklin and Sterling Hill - A Check List. Wiley Interscience.
  5. 1985Dunn, Pete J. (1985) The lead silicates from Franklin, New Jersey: occurrence and composition. Mineralogical Magazine, 49 (354) 721-727 doi:10.1180/minmag.1985.049.354.12 DOI: 10.1180/minmag.1985.049.354.12
