Pumpellyite-(Mg)

Ca2MgAl2(Si2O7)(SiO4)(OH)2 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pmp-Mg
Also known as
  • Pumpellyiet-(Mg)
  • Zonochlorite

Where it forms, where it's found

Type locality
Keweenaw County
  1. Michigan
  2. USA
111recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Green · blue · blackish green · brown
Streak
White
Cleavage
Distinct/Good

Distinct on (001) and (100).

Density
3.18 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 70 – 90° · 2V calc = 32 – 76°
Refractive index
1.674 – 1.764
Surface relief
High
Principal indices
nα 1.674 – 1.748 · nβ 1.675 – 1.754 · nγ 1.688 – 1.764
Pleochroism
Strong

X = nearly colorless to pale greenish yellow; Y = blue-green; Z = almost colorless to brownish yellow.

Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 8.83(1) Å · b = 5.90(1) Å · c = 19.17(2) Å
Cell angles
β = 97.10 °
Ratio a:b:c
1 : 0.668 : 2.171
Z
4
Morphology

Bladed, typically elongated along [010]; in stellate clusters, fibrous, or dense mats.

Twinning

Common on (001) and (100)

Comment

Non-standard space group A2/m.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
47.59%
14SiSiliconSilicon328.08584.255
17.90%
20CaCalciumCalcium240.07880.156
17.03%
13AlAluminiumAluminium226.98253.964
11.46%
12MgMagnesiumMagnesium124.30524.305
5.16%
1HHydrogenHydrogen41.0084.032
0.86%
Total470.698100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Pumpellyiet-(Mg)
  • Zonochlorite

In other languages

German
Pumpellyit-(Mg)
Italian
Pumpellyite- · Pumpellyite-(Mg)

Classification

Strunz
10th ed.

9.BG.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.20Pumpellyite-(Mg)Species
Dana
8th ed.

58.02.02.07

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.02Pumpellyite groupGroup
  • 58.02.02.07Pumpellyite-(Mg)Species
CIM

16.11.7

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.11Aluminosilicates of Ca and Mg with or without alkalisGroup
  • 16.11.7Pumpellyite-(Mg)Species

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1925Palache, Charles, Vassar, Helen E. (1925) Some minerals of the Keweenawan copper deposits: Pumpellyite, a new mineral; sericite; saponite. American Mineralogist, 10 (11). 412-418
  2. 1926Foshag, W.F. (1926) New mineral names. American Mineralogist, 11, 216-220.
  3. 1953Coombs, D. S. (1953) The pumpellyite mineral series. Mineralogical Magazine and Journal of the Mineralogical Society, 30 (221) 113-135 doi:10.1180/minmag.1953.030.221.04 DOI: 10.1180/minmag.1953.030.221.04
  4. 1973Passaglia, Elio, Gottardi, Glauco (1973) Crystal chemistry and nomenclature of pumpellyites and julgoldites. The Canadian Mineralogist, 12 (3) 219-223
  5. 1976Fleischer, Michael, Pabst, Adolf, Mandarino, Joseph A., Chao, George Y., Cabri, Louis, J. (1976) New Mineral Names. American Mineralogist, 61 (1-2) 174-186
