Schoenfliesite

MgSn(OH)6
IMA status
  • Approved
IMA symbol
Sfs
Discovered
1968
IMA approved
1968
Also known as
  • IMA1968-008
  • Schoenfliesiet
  • Schönfliesit
  • +1 more

Where it forms, where it's found

Geological setting

Hydrothermal alteration of boron-enriched contact metamorphosed limestone.

Serpentinized dolostone in contact with B-Be-Sr-W skarn

Type locality
Brooks Mountain
  1. York Mountains
  2. Port Clarence Mining District
  3. Nome Census Area
  4. Alaska
  5. USA

65.5390°, -167.1305°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dark red-brown · yellow · orange · greenish yellow
Streak
Nearly white, lighter than massive mineral
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.32 g/cm³

Optical

Optical type
Isotropic
Surface relief
High
Principal indices
n 1.667
Birefringence
0.0
Pleochroism
Non-pleochroic
UV response
Not fluorescent in UV
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.667

Crystallography

Crystal system
Isometric
Space group
Pn3
Cell parameters
a = 7.759(6) Å
Z
4
Morphology

Octahedral, usually massive.

Type-locality form

Very fine-grained particles, less than 10 microns in size.

Comment

Data for synthetic material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
50SnTinTin1118.710118.710
48.44%
8OOxygenOxygen615.99995.994
39.17%
12MgMagnesiumMagnesium124.30524.305
9.92%
1HHydrogenHydrogen61.0086.048
2.47%
Total245.057100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1968-008
  • Schoenfliesiet
  • Schönfliesit
  • Schönfliesite

In other languages

German
IMA 1968-008 · Schoenfliesit
Spanish
Schoenfliesita
Italian
Schoenfliesite

Classification

Strunz
10th ed.

4.FC.10

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FCHydroxides with OH, without H2O; corner-sharing octahedraGroup
  • 4.FC.10SchoenfliesiteSpecies
Dana
8th ed.

06.03.06.02

  • 06Hydroxides and Oxides Containing HydroxylClass
  • 06.03X(OH)3Type
  • 06.03.06Wickmanite group (Cubic or Trigonal, 2+ cations containing Sn)Group
  • 06.03.06.02SchoenfliesiteSpecies
CIM

7.11.4

  • 7Oxides and HydroxidesClass
  • 7.11Oxides of Sn and PbGroup
  • 7.11.4SchoenfliesiteSpecies

Group, growth & confusion

In the same group
6 members
Often grow together
8 minerals

Literature, links & citation

Citations
  1. 1960Strunz, H., Contag, B. (1960) Hexahydroxostannate Fe, Mn, Co, Mg, Ca[Sn(OH)6] und deren Kristallstruktur. Acta Crystallographica, 13 (8) 601-603 doi:10.1107/s0365110x60001436DOI: 10.1107/s0365110x60001436
  2. 1971Faust G T, Schaller W T (1971) Schoenfliesite, MgSn(OH)6. Zeitschrift für Kristallographie 134, 116-141
  3. 1972Fleischer, Michael (1972) New Mineral Names. American Mineralogist, 57 (9-10) 1552-1561
  4. 1977Nefedov, E.I., Griffin, W.L., Kristiansen, R. (1977) Minerals of the schoenfliesite-wickmanite series from Pitkaranta, Karelia, U.S.S.R.. The Canadian Mineralogist: 15(4): 437–445.
  5. 1998Basciano, L. C., Peterson, R. C., Roeder, P. L., Swainson, I. (1998) Description of schoenfliesite, MgSn(OH) 6 , and roxbyite, Cu (sub 1.72) S, from a 1375 BC shipwreck, Rietveld neutron-diffraction refinement of synthetic schoenfliesite, wickmanite, MnSn(OH) 6, and burtite, CaSn(OH)6 . The Canadian Mineralogist, 36 (5). 1203-1210
