Swinefordite

Ca0.2(Li,Al,Mg,Fe)3(Si,Al)4O10(OH,F)2 · nH2O
IMA status
  • Approved
IMA symbol
Sfd
Discovered
1973
IMA approved
1973
Also known as
  • IMA1973-054
  • Swinefordiet

Where it forms, where it's found

Type locality
Foote Lithium Co. Mine
  1. Kings Mountain
  2. Cleveland County
  3. North Carolina
  4. USA

35.2111°, -81.3556°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy
Colour
White · greenish yellow · dark olive-gray
Streak
White
Tenacity
waxy
Cleavage

[001] Perfect

Optical

Optical type
Biaxial (-) · 2V measured = 29 – 45° · 2V calc = 37°
Refractive index
1.492 – 1.526
Surface relief
Moderate
Principal indices
nα 1.492 · nβ 1.524 · nγ 1.526
Pleochroism
Weak

Y = almost colorless; Z = pale yellow-brown

Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.2 Å · b = 9.0 Å · c = 13.0 Å
Ratio a:b:c
1 : 1.731 : 2.500
Morphology

Resembles petroleum jelly when hydrated; on dehydration, becomes fibrous, in thin ribbons, folded and twisted, and in curled sheets

Comment

Z n.d.

Chemical composition

Impurities
  • Al
  • Fe

Synonyms

  • IMA1973-054
  • Swinefordiet

In other languages

German
IMA 1973-054 · Swinefordit
Italian
Swinefordite

Classification

Strunz
10th ed.

9.EC.45

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.45SwineforditeSpecies
Dana
8th ed.

71.03.1a.05

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.03Sheets of 6-membered rings with 2:1 claysType
  • 71.03.1a— unnamed intermediate level —Group
  • 71.03.1a.05SwineforditeSpecies
CIM

16.1.8

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.1Aluminosilicates of LiGroup
  • 16.1.8SwineforditeSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1975Tien, Pei-lin, Leavens, Peter B., Nelen, Joseph A. (1975) Swinefordite, a dioctahedral-trioctahedral Li-rich member of the smectite group from Kings Mountain, North Carolina. American Mineralogist, 60 (7-8) 540-547
  2. 2001(2001) Swinefordite. Handbook of Mineralogy. Mineralogical Society of America
