Wonesite

(Na,K,◻)(Mg,Fe,Al)6(Si,Al)8O20(OH,F)4
IMA status
  • Approved
IMA symbol
Wns
Discovered
1981
Also known as
  • Wonesiet

Where it forms, where it's found

Geological setting

In metavolcanics with high Mg:Fe, moderate sodium, and very little calcium, metamorphosed at an estimated 535C.

Type locality
Post Pond Volcanics
  1. Mt Cube Quadrangle
  2. Norwich
  3. Windsor County
  4. Vermont
  5. USA
4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Golden yellow-brown
Streak
White
Tenacity
flexible
Cleavage
Perfect

(001)

Fracture
Micaceous
Density
2.89 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5°
Refractive index
1.544 – 1.608
Surface relief
Moderate
Principal indices
nα 1.544 · nβ 1.608 · nγ 1.608
Birefringence
0.064
Pleochroism
Strong

X pale brown Y,Z dark brown

Dispersion
weak
Extinction
Parallel
Notes

Bird's Eye Maple extinction; resembles biotite, RI similar to phlogopite

Michel-Lévy diagramhighlighted lineδ = 0.0640
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]640 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation640 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 5.312 Å · b = 9.163 Å · c = 9.825 Å
Cell angles
β = 103.18 °
Ratio a:b:c
1 : 1.725 : 1.850
Z
2
Morphology

Anhedral plates

Twinning

Twin plane (001) with twin axis [310]

Type-locality form

Coarse (~0.25-0.5 cm) intergrown plates of flat sheets.

Crystal structure

Chemical composition

Impurities
  • Ti
  • Cr
  • Mn
  • Ca
  • H2O

Synonyms

  • Wonesiet

In other languages

German
IMA 1979-007a · Wonesit
Italian
Wonesite
Chinese
翁钠金云母

Classification

Strunz
10th ed.

9.EC.20

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.ECPhyllosilicates with mica sheets, composed of tetrahedral and octahedral netsGroup
  • 9.EC.20WonesiteSpecies
Dana
8th ed.

71.02.2b.14

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.02Sheets of 6-membered rings with 2:1 layersType
  • 71.02.2b— unnamed intermediate level —Group
  • 71.02.2b.14WonesiteSpecies
CIM

16.20.6

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.20Aluminosilicates of Fe, Mg and alkalisGroup
  • 16.20.6WonesiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. Dera, P., Rapp, R., Chornkrathok, S., Zhang, D., Prakapenka, V.B., Woźniak, K. (2023). New high-pressure phase of CaSiO3 wollastonite with penta-coordinated silicon. 9th Meeting of the Mineralogical Society of Poland / 28th Meeting of the Petrology group of the Mineralogical Society of Poland, "Oceanic lithosphere: rocks, minerals, and critical resources", October 19-22, Bielawa, Poland. Mineralogia - Special Papers, 51, 51.
  2. 1977Spear, F.S., Hazen, R.M., Rumble, D., III (1977) Sodium trioctahedral mica: A possible new rock-forming silicate from the Post Pond Volcanics, Vermont. Carnegie Institution of Washington Year Book: 77: 808-811.
  3. 1981Spear, Frank S., Hazen, Robert M., III, Douglas Rumble (1981) Wonesite: a new rock-forming silicate from the Post Pond Volcanics, Vermont. American Mineralogist, 66 (1-2) 100-105
  4. 1983Veblen, David R. (1983) Exsolution and crystal chemistry of the sodium mica wonesite. American Mineralogist, 68 (5-6) 554-565
  5. 1983Veblen, David R. (1983) Microstructures and mixed layering in intergrown wonesite, chlorite, talc, biotite and kaolinite. American Mineralogist, 68 (5-6) 566-580
