Xanthoxenite

Ca4Fe3+2(PO4)4(OH)2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Xox
Discovered
1949
Also known as
  • Xanthoxen
  • Xanthoxeniet
  • Xanthoxenite (of Frondel)

Where it forms, where it's found

Type locality
Hühnerkobel Mine (Hennenkobel Mine)
  1. Rabenstein
  2. Zwiesel
  3. Regen District
  4. Lower Bavaria
  5. Bavaria
  6. Germany

49.0517°, 13.1697°

31recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Waxy
Transparency
Translucent
Colour
Pale yellow · brownish-yellow · pale yellow to pale lemon-yellow in transmitted light.
Cleavage
Perfect

On (010), perfect.

Density
2.97 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80 – 90° · 2V calc = 82°
Refractive index
1.704 – 1.724
Surface relief
High
Principal indices
nα 1.704 · nβ 1.715 · nγ 1.724
Pleochroism
Weak

In thick grains in shades of yellow.

Dispersion
r > v weak
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.7 Å · b = 8.85 Å · c = 6.54 Å
Cell angles
α = 92.1 ° · β = 110.1 ° · γ = 93.2 °
Ratio a:b:c
1 : 1.321 : 0.976
Z
1
Comment

Point group may be 1.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2115.999335.979
45.41%
20CaCalciumCalcium440.078160.312
21.67%
15PPhosphorusPhosphorus430.974123.896
16.74%
26FeIronIron255.845111.690
15.09%
1HHydrogenHydrogen81.0088.064
1.09%
Total739.941100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Xanthoxen
  • Xanthoxeniet
  • Xanthoxenite (of Frondel)

In other languages

French
Xanthoxenite
German
IMA 1975-004a · Xanthoxenit
Spanish
xantoxenita · Xantoxeno
Italian
Xanthoxenite

Classification

Strunz
10th ed.

8.DH.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DH.40XanthoxeniteSpecies
Dana
8th ed.

42.11.15.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.15— unnamed intermediate level —Group
  • 42.11.15.01XanthoxeniteSpecies
CIM

19.14.15

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.15XanthoxeniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1915Laubmann, H.; Steinmetz, H. (1915) Phosphatführende Pegmatite des Oberpfälzer und Bayerischen Waldes. Zeitschrift für Kristallographie, Mineralogie und Petrographie, 55 (1-6). 523-586 doi:10.1524/zkri.1915.55.1.523DOI: 10.1524/zkri.1915.55.1.523
  2. 1949Frondel, Clifford (1949) Wolfeite, xanthoxenite and whitlockite from the Palermo Mine, New Hampshire. American Mineralogist, 34 (9-10) 692-705
  3. 1949Mineralogical Magazine, (1949): 34, 692.
  4. 1970Staněk, J. (1970): Kakoxen und Xanthoxen von Dolní Bory. Acta Musei Moraviae, Sci. nat., 55, 5-12. (in German)
  5. 1978Moore, Paul Brian, Ito, Jun (1978) I. Whiteite, a new species, and a proposed nomenclature for the jahnsite-whiteite complex series. II. New data on xanthoxenite. III. Salmonsite discredited. Mineralogical Magazine, 42 (323) 309-323 doi:10.1180/minmag.1978.042.323.01 DOI: 10.1180/minmag.1978.042.323.01
