Monticellite

CaMg(SiO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mtc
Discovered
1831
Also known as
  • Shannonite (of Tilley)

Where it forms, where it's found

Type locality
Mount Somma
  1. Metropolitan City of Naples
  2. Campania
  3. Italy
170recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Colourless · grey or greenish
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

Poor on (010).

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.03 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 88 – 65° · 2V calc = 72 – 84°
Refractive index
1.639 – 1.68
Surface relief
High
Principal indices
nα 1.639 – 1.663 · nβ 1.645 – 1.674 · nγ 1.653 – 1.680
Dispersion
relatively weak
Extinction
X = b; Y = c; Z = a.
Michel-Lévy diagramhighlighted lineδ = 0.0155
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]155 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation155 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.815 Å · b = 11.08 Å · c = 6.37 Å
Ratio a:b:c
1 : 2.301 : 1.323
Z
4
Morphology

Well-formed prismatic crystals, to 5 cm; massive, granular.

Twinning

On (031), producing six-pointed star-shaped forms.

Type-locality form

Crystals with a general shape similar to quartz.

Comment

Space group: Pbnm (non-standard setting).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
40.90%
20CaCalciumCalcium140.07840.078
25.62%
14SiSiliconSilicon128.08528.085
17.95%
12MgMagnesiumMagnesium124.30524.305
15.53%
Total156.464100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mn
  • Zn
  • H2O

Synonyms

  • Shannonite (of Tilley)

In other languages

French
monticellite
German
Monticellit
Spanish
Monticellita
Italian
Monticellite
Portuguese
monticellite
Chinese
錳鎂橄欖石
Russian
монтичеллит

Classification

Strunz
10th ed.

9.AC.10

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ACNesosilicates without additional anions; cations in octahedral [6] coordinationGroup
  • 9.AC.10MonticelliteSpecies
Dana
8th ed.

51.03.02.01

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.03Insular SiO4 Groups Only with all cations in octahedral [6] coordinationType
  • 51.03.02Monticellite - Kirschsteinite seriesGroup
  • 51.03.02.01MonticelliteSpecies
CIM

14.6.10

  • 14Silicates not Containing AluminumClass
  • 14.6Silicates of Ca with alkali or Mg or bothGroup
  • 14.6.10MonticelliteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1831Brooke, H.J. (1831) On Monticellite, a new Species of Mineral. The Philosophical Magazine, Or Annals of Chemistry, Mathematics, Astronomy, Natural History and General Science: 10: 265-266.
  2. 1928Brown, G.B. and West, J. (1928) Zeitschrift für Kristallografie: 66: 154.
  3. 1935Schaller, Waldemar T. (1935) Monticellite from San Bernardino County, California, and the monticellite series. American Mineralogist, 20 (12) 815-827
  4. 1952Neuvonen, Kalle J. (1952), Heat of formation of Merwinite and monticellite: American Journal of Science, Bowen volume: 373-380.
  5. 1964Onken, Hajo (1964) Verfeinerung der Kristallstruktur von Monticellit. Die Naturwissenschaften, 51 (14). 334-335 doi:10.1007/bf00625077DOI: 10.1007/bf00625077
