Cornubite

Cu5(AsO4)2(OH)4
IMA status
  • Approved
IMA symbol
Cnb
Discovered
1958
Also known as
  • Cornubiet
  • Corunuvit
  • Corunuvite
  • +3 more

Where it forms, where it's found

Geological setting

Copper-Tin-Silver bearing hydrothermal veins.

Oxidation zone of copper deposits.

Type locality
Wheal Carpenter
  1. Fraddam
  2. Gwinear-Gwithian
  3. Cornwall
  4. England
  5. UK

50.1678°, -5.3806°

115recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Apple green · light to dark green
Streak
Pale green
Tenacity
brittle
Cleavage
Distinct/Good

Two perpendicular to (211), intersecting about 70°.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
4.64 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.87 – 1.9
Surface relief
Very high
Principal indices
nα 1.87 · nγ 1.90
Birefringence
0.03
Pleochroism
Non-pleochroic
Dispersion
r > v
UV response
Not Fluorescent
Notes

2V very large, beta N.D.

Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 6.121(1) Å · b = 6.251(1) Å · c = 6.790 Å
Cell angles
α = 92.93(1) ° · β = 111.30 ° · γ = 107.47(1) °
Ratio a:b:c
1 : 1.021 : 1.109
Z
1
Morphology

Rarely in crystals in tabular aggregates, usually botyroidal, also globular porcelaneous masses, fibrous.

Type-locality form

Apple-green patches of fibrous botryoids.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper563.546317.730
47.88%
8OOxygenOxygen1215.999191.988
28.93%
33AsArsenicArsenic274.922149.844
22.58%
1HHydrogenHydrogen41.0084.032
0.61%
Total663.594100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cornubiet
  • Corunuvit
  • Corunuvite
  • Corvunvit
  • Corvunvita
  • Corvunvite

In other languages

French
Cornubite
German
Cornubit
Spanish
Cornubita
Italian
Cornubite
Chinese
綠砷銅礦

Classification

Strunz
10th ed.

8.BD.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BDWith only medium-sized cations, (OH, etc.):RO4= 2:1Group
  • 8.BD.30CornubiteSpecies
Dana
8th ed.

41.04.02.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.04(AB)5(XO4)2ZqType
  • 41.04.02— unnamed intermediate level —Group
  • 41.04.02.01CornubiteSpecies
CIM

20.1.5

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.1Arsenates of CuGroup
  • 20.1.5CornubiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1959Fleischer, M. (1959) New Mineral Names. American Mineralogist, 44 (11-12). 1321-1329
  2. 1959Claringbull, G. F., Hey, M. H., Davis, R. J. (1959) Cornubite, a new mineral dimorphous with cornwallite. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (244) 1-5 doi:10.1180/minmag.1959.032.244.01 DOI: 10.1180/minmag.1959.032.244.01
  3. 1961Laurent, Yvette, Pierrot, Roland (1961) Sur la présence de cornubite au cap Garonne (Var) Bulletin de Minéralogie, 84 (3) 318-319 doi:10.3406/bulmi.1961.5496DOI: 10.3406/bulmi.1961.5496
  4. 1962(1962) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258) 260-263 doi:10.1180/minmag.1962.033.258.09 DOI: 10.1180/minmag.1962.033.258.09
  5. 1984Hyršl, J., Korbel, P., Šourek, J. (1984): Cornubit a cornwallit z Farbiště u Ponické Lehotky. Čas. Mineral. Geol., 29, 4, 433-434.
