Fuettererite

Pb3Cu2+6Te6+O6(OH)7Cl5
IMA status
  • Approved
IMA symbol
Fue
IMA approved
2012
Also known as
  • Fuettereriet
  • IMA2011-111

Where it forms, where it's found

Geological setting

In vugs in quartz; originated by partial oxidation of primary sulfide and telluride minerals during/following brecciation of the quartz veins

Bird Nest drift specimen

Type locality
NE2 vein
  1. Otto Mountain
  2. Baker
  3. Soda Mountains
  4. Silver Lake Mining District
  5. San Bernardino County
  6. California
  7. USA

35.2778°, -116.0933°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Bluish green
Streak
Pale bluish-green
Tenacity
brittle
Cleavage
Perfect

on (001).

Fracture
Irregular/Uneven
Density
5.528 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.97 – 2.04
Surface relief
Very high
Principal indices
nω 2.04 · nε 1.97
Notes

Dichroic bluish-green, E < O.

Michel-Lévy diagramhighlighted lineδ = 0.0700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]700 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation700 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R3
Cell parameters
a = 8.4035(12) Å · c = 44.681(4) Å
Unit cell volume
2732.6 ų
Z
6
Morphology

Tabular to short prismatic, exhibit the forms (100), (101), and (001) and reach a maximum dimension of 50 μm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
40.82%
29CuCopperCopper663.546381.276
25.04%
8OOxygenOxygen1315.999207.987
13.66%
17ClChlorineChlorine535.450177.250
11.64%
52TeTelluriumTellurium1127.600127.600
8.38%
1HHydrogenHydrogen71.0087.056
0.46%
Total1522.769100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fuettereriet
  • IMA2011-111

In other languages

German
Fuettererit · IMA 2011-111
Italian
fuettererite

Classification

Strunz
10th ed.

4.FE.50

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FEHydroxides with OH, without H2O; sheets of edge-sharing octahedraGroup
  • 4.FE.50FuettereriteSpecies

Group, growth & confusion

Often grow together
14 minerals

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 13. Mineralogical Magazine, 76 (3) 807-817 doi:10.1180/minmag.2012.076.3.26 DOI: 10.1180/minmag.2012.076.3.26
  2. 2013Kampf, A. R., Mills, S. J., Housley, R. M., Marty, J. (2013) Lead-tellurium oxysalts from Otto Mountain near Baker, California: VIII. Fuettererite, Pb3Cu2+6Te6+O6(OH)7Cl5, a new mineral with double spangolite-type sheets. American Mineralogist, 98 (2) 506-511 doi:10.2138/am.2013.4218 DOI: 10.2138/am.2013.4218
  3. 2017(2017) Fuettererite. Handbook of Mineralogy. Mineralogical Society of America
