Clinoatacamite

Cu2Cl(OH)3
IMA status
  • Approved
IMA symbol
Cata
Also known as
  • Anatacamite
  • Clinoatacamiet
  • Clinoatacamit
  • +2 more

Where it forms, where it's found

Type locality
Chuquicamata Mine
  1. Chuquicamata District
  2. Calama
  3. El Loa Province
  4. Antofagasta
  5. Chile

-22.2894°, -68.9011°

59recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine.
Transparency
Transparent · Translucent
Colour
Green to dark greenish-black · greenish-blue.
Streak
Green to white.
Tenacity
very brittle
Cleavage
Perfect

Perfect on (012)

Fracture
Step-Like
Density
3.77 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 75° · 2V calc = 80°
Refractive index
1.83 – 1.88
Surface relief
Very high
Principal indices
nα 1.83 · nβ 1.85 · nγ 1.88
Dispersion
strong
Luminescence
None.
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.157(2) Å · b = 6.814(3) Å · c = 9.105(5) Å
Cell angles
β = 99.65(4) °
Ratio a:b:c
1 : 1.107 : 1.479
Z
4
Morphology

Pseudo-rhombohedral; complex intergrowths/twins.

Twinning

Very common, on (100).

Type-locality form

As complex intergrowths of crystals and twinned grains,

Comment

Space Group: P21/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper263.546127.092
59.51%
8OOxygenOxygen315.99947.997
22.47%
17ClChlorineChlorine135.45035.450
16.60%
1HHydrogenHydrogen31.0083.024
1.42%
Total213.563100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Anatacamite
  • Clinoatacamiet
  • Clinoatacamit
  • IMA1993-060
  • Klinoatakamit

In other languages

German
IMA 1993-060 · Klinoatacamit
Italian
Clinoatacamite

Classification

Strunz
10th ed.

3.DA.10b

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.10bClinoatacamiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (6) 463-466
  2. 1996Jambor, John L., Dutrizac, John E., Roberts, Andrew C., Grice, Joel D., Szymanski, Jan T. (1996) Clinoatacamite, a new polymorph of Cu2(OH)3Cl, and its relationship to paratacamite and "anarakite". The Canadian Mineralogist, 34 (1) 61-72
  3. 1996Grice, Joel D., Szymański, J. T., Jambor, J. L. (1996) The crystal structure of clinoatacamite, a new polymorph of Cu2(OH)3Cl. The Canadian Mineralogist, 34 (1) 73-78
  4. 2005(2005) Clinoatacamite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Malcherek, T. and Schlüter, J. (2008) The crystal structure of clinoatacamite and the quest for paratacamite. Poster, Annual Meeting of the DMG, Berlin, Germany, September 14-17, 2008; CD with abstracts, Abs. no. 527.
