Götzenite

Ca4NaCa2Ti(Si2O7)2(OF)F2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Göz
Discovered
1954
Also known as
  • Calcium-Rinkite
  • Goetzenite
  • Götzeniet

Where it forms, where it's found

Geological setting

Nephelinite

Hornfels and marble xenoliths

Type locality
Mount Shaheru
  1. Nyiragongo Volcano
  2. Nyiragongo Territory
  3. North Kivu
  4. DR Congo

-1.4833°, 29.2333°

35recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Dull to greasy to vitreous.
Transparency
Transparent
Colour
Very pale yellow · tan · off-white · colorless · white · brown.

Colorless in thin section (TL)

Streak
White
Cleavage
Perfect

Perfect on (100), good on (001)

Density
3.03 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 38 – 74° · 2V calc = 62 – 68°
Refractive index
1.651 – 1.672
Surface relief
High
Principal indices
nα 1.651 – 1.662 · nβ 1.653 – 1.665 · nγ 1.659 – 1.672
Dispersion
r > v strong
Luminescence
(not reported)
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.6191(3) Å · b = 5.7342(2) Å · c = 7.3386(2) Å
Cell angles
α = 89.986(1) ° · β = 101.040(1) ° · γ = 100.485(1) °
Ratio a:b:c
1 : 0.596 : 0.763
Z
1
Morphology

Prismatic, acicular, skeletal.

Twinning

Lamellar twinning on (001) ubiquitous shows rotation twinning on [001]

Type-locality form

As prismatic crystals up to 0.5 mm long.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium640.078240.468
33.37%
8OOxygenOxygen1515.999239.985
33.30%
14SiSiliconSilicon428.085112.340
15.59%
9FFluorineFluorine318.99856.994
7.91%
22TiTitaniumTitanium147.86747.867
6.64%
11NaSodiumSodium122.99022.990
3.19%
Total720.644100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Calcium-Rinkite
  • Goetzenite
  • Götzeniet

In other languages

German
Götzenit
Italian
Götzenite

Classification

Strunz
10th ed.

9.BE.22

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.22GötzeniteSpecies
Dana
8th ed.

56.02.05.04

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.05Mosandrite and related speciesGroup
  • 56.02.05.04GötzeniteSpecies
CIM

17.2.7

  • 17Silicates Containing other AnionsClass
  • 17.2Silicates with fluorideGroup
  • 17.2.7GötzeniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1957Sahama, Th. G., Hytönen, Kai (1957) Götzenite and combeite, two new silicates from the Belgian Congo. Mineralogical Magazine and Journal of the Mineralogical Society, 31 (238). 503-510 doi:10.1180/minmag.1957.031.238.01DOI: 10.1180/minmag.1957.031.238.01
  2. 1958Fleischer, M. (1958) New Mineral Names. American Mineralogist, 43 (7-8). 790-798
  3. 1962(1962) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258) 260-263 doi:10.1180/minmag.1962.033.258.09 DOI: 10.1180/minmag.1962.033.258.09
  4. 1972Cannillo, E., Mazzi, F. & Rossi, G. (1972) Crystal structure of gotzenite. Soviet Physics - Crystallography: 16(6): 1026-1030.
  5. 2000Christiansen, C.C., Rønsbo, J.G. (2000): On the structural relationship between götzenite and rinkite. Neues Jahrbuch für Mineralogie, Monatshefte, 2000, 496-506.
