Hainite-(Y)

(Ca3Y)Na(NaCa)Ti(Si2O7)2(OF)F2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hai-Y
Discovered
1893
Also known as

Where it forms, where it's found

Geological setting

Cavities and groundmass of phonolites (TL material); carbonatites

Type locality
Hohe Hain Mountain
  1. Raspenava
  2. Liberec District
  3. Liberec Region
  4. Czech Republic

50.9156°, 15.1636°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Wine-yellow · honey-yellow · milk white · brownish · pale pink

Light wine-yellow in thin section. Altered hainite-(Y9 shows a brown colour

Streak
White
Tenacity
brittle
Cleavage
Perfect

Rather perfect, (010); also faint on (100)

Fracture
Irregular/Uneven
Density
3.157-3.274 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 30 – 45° · 2V calc = 33.7°
Refractive index
1.663 – 1.675
Surface relief
High
Principal indices
nα 1.663 · nβ 1.664 · nγ 1.675
Birefringence
~0.012
Pleochroism
Visible

colorless (X), colorless to pale yellow (Y), wine-yellow (Z)

Dispersion
relatively strong (r > v)
Notes

2V(meas.): large

Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.594 Å · b = 5.702 Å · c = 7.288 Å
Cell angles
α = 89.89(4) ° · β = 101.09(4) ° · γ = 101.17(4) °
Ratio a:b:c
1 : 0.594 : 0.760
Unit cell volume
383.55 ų
Z
1
Twinning

on (100)

Type-locality form

Crystals, less than 1 mm, needles and plates, [001] elongation; (010), (100), and (110) faces present (TL material)

Comment

parameters of the TL material: a=5.676(2), b=7.259(3), c=9.586(3), α=101.08(4), β=101.14(4), γ=90.27(4)

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
31.90%
20CaCalciumCalcium440.078160.312
21.31%
14SiSiliconSilicon428.085112.340
14.93%
39YYttriumYttrium188.90688.906
11.82%
9FFluorineFluorine318.99856.994
7.57%
22TiTitaniumTitanium147.86747.867
6.36%
11NaSodiumSodium222.99045.980
6.11%
Total752.384100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Ce
  • La
  • Fe
  • Nb
  • Ta
  • Al

Synonyms

  • Gainit
  • Gainita
  • Gainite
  • Giannettit
  • Giannettita
  • Giannettite
  • Hainiet-(Y)
  • Hainit
  • Hainita
  • Hainite

In other languages

German
Hainit-(Y)
Italian
Hainite- · hainite-(Y)

Classification

Strunz
10th ed.

9.BE.22

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.22Hainite-(Y)Species
Dana
8th ed.

56.02.04.09

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.04Cuspidine - Wohlerite groupGroup
  • 56.02.04.09Hainite-(Y)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1893Blumrich, J. (1893) Die Phonolithe des Friedländer Bezirkes in Nordböhmen, Zeitschrift für Kristallographie, Mineralogie und Petrographie: 13: 6: 465-495.
  2. 1989Johan, Z. and Cech, F. (1989) New data on hainite, Na2Ca4(Ti,Zr,Mn,Fe,Nb,Ta)1.500.50)(Si2O7)2F4 and its crystallochemical relationship with götzenite, Na2Ca5Ti(Si2O7)2F4. Comptes Rendus de l'Academie des Sciences: Série II: 308: 1237-1242 (in French).
  3. 1995Rastsvetaeva, R.K., Pushcharovsky, D.Y, and Atencio, D. (1995) Crystal structure of giannetite. Crystallography Reports 40(4): 574-578.
  4. 1999Atencio, D., Coutinho, J. M. C., Ulbrich, M. N. C., Vlach, S. R. F., Rastvetaeva, R. K., Pushcharovsky, D. Yu. (1999) Hainite from Poços de Caldas, Minas Gerais, Brazil. The Canadian Mineralogist, 37 (1) 91-98
  5. 2001(2001) Hainite-(Y). Handbook of Mineralogy. Mineralogical Society of America
