Rinkite-(Ce)

(Ca3REE)Na(NaCa)Ti(Si2O7)2(OF)F2
IMA status
  • Approved
IMA symbol
Rin-Ce
Discovered
1884
IMA approved
2009
Also known as
  • Johnstrupite
  • Rinkiet-(Ce)
  • Rinkit
  • +2 more

Where it forms, where it's found

Type locality
Kangerluarsuk Fjord
  1. Ilímaussaq complex
  2. Kujalleq
  3. Greenland

60.8759°, -45.8737°

57recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · greasy
Colour
Yellowish-brown · yellow · brown
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (100).

Fracture
Irregular/Uneven · Conchoidal
Density
3.18 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 43° · 2V calc = 52°
Refractive index
1.665 – 1.681
Surface relief
High
Principal indices
nα 1.665 · nβ 1.668 · nγ 1.681
Dispersion
strong
Extinction
X ∧ c = 3°.
Notes

Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.441 Å · b = 5.663 Å · c = 18.832 Å
Cell angles
β = 101.383 °
Ratio a:b:c
1 : 0.761 : 2.531
Z
2
Morphology

Crystals prismatic along [001] and flattened on (100) with {hk0} faces strongly striated.

Twinning

Lamellar, polysynthetic on (100).

Crystal structure

Chemical composition

Impurities
  • Zr
  • Th
  • Y
  • La
  • Fe
  • Mn
  • Mg
  • K
  • H2O

Synonyms

  • Johnstrupite
  • Rinkiet-(Ce)
  • Rinkit
  • Rinkita
  • Rinkite

In other languages

German
2016 s.p. · Rinkit · Rinkit-(Ce)
Italian
Rinkite- · rinkite-(Ce)

Classification

Strunz
10th ed.

9.BE.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.20Rinkite-(Ce)Species

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1884Lorenzen, Joh. (1884) XII. Untersuchung einiger Mineralien aus Kangerdluarsuk in Grönland. Zeitschrift für Kristallographie - Crystalline Materials, 9 (1) 243 doi:10.1524/zkri.1884.9.1.243DOI: 10.1524/zkri.1884.9.1.243
  2. 1957Slepnev, Yu.S. (1957) On the minerals of the rinkite group. Izvestiya Akademii Nauk SSSR: 1957(3): 63-75.
  3. 1958Fleischer, F. (1958) New Data - Rinkite, Johnstrupite, Rinkolite, Lovchorrite,and Calcium Rinkite (all: Mosandrite). American Mineralogist: 43: 790.
  4. 1966Gottardi, Glauco (1966) X-ray crystallography of rinkite. American Mineralogist, 51 (9-10) 1529-1534
  5. 1967Simonov, V.I., Belov, N.V. (1967) Characteristics of the crystal structure of rinkite. Soviet Physics - Crystallography: 12: 740-744.
