Grenmarite

Na2Zr2Na2MnZr(Si2O7)2O2F2
IMA status
  • Approved
IMA symbol
Grn
Discovered
1989
IMA approved
2003
Also known as
  • Grenmariet
  • IMA2003-024

Where it forms, where it's found

Geological setting

Nepheline syenite pegmatite

Type locality
Natrolittodden
  1. Vesle Arøya
  2. Larvik Commune
  3. Vestfold
  4. Norway

59.0108°, 9.7963°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Yellowish brown to dark brown
Streak
Pale yellowish brown
Tenacity
brittle
Cleavage
Distinct/Good

(001)

Fracture
Irregular/Uneven
Density
3.49 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.694 – 1.735
Surface relief
High
Principal indices
nα 1.694 · nγ 1.735
Birefringence
birefringence on (001) is 0.041
Pleochroism
Visible

Light Brown Colorless

Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/c
Cell parameters
a = 5.6082 Å · b = 7.1387 Å · c = 18.575 Å
Cell angles
β = 102.6 °
Ratio a:b:c
1 : 1.273 : 3.312
Unit cell volume
725.72 ų
Z
2
Morphology

Elongated, flattened crystals; semi-parallel and radiating aggregates. Crystals are striated parallel to [010] and often slightly curved. Dominated forms observed: pinacoids (201) and {20-3}

Type-locality form

Embedded in microcline and fine-grained albite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
40ZrZirconiumZirconium391.224273.672
33.10%
8OOxygenOxygen1615.999255.984
30.96%
14SiSiliconSilicon428.085112.340
13.59%
11NaSodiumSodium422.99091.960
11.12%
25MnManganeseManganese154.93854.938
6.64%
9FFluorineFluorine218.99837.996
4.59%
Total826.890100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Grenmariet
  • IMA2003-024

In other languages

German
Grenmarit · IMA 2003-024
Italian
Grenmarite

Classification

Strunz
10th ed.

9.BE.25

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.25GrenmariteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1996Andersen, Frode; Berge, Svein Arne; Burvald, Ingulv (1996) Die Mineralien des Langesundsfjords und des umgebenden Larvikit-Gebietes, Oslo-Region, Norwegen. Mineralien Welt, 7 (4). 21-100
  2. 2004Bellezza, Marco, Franzini, Marco, Larsen, Alf O., Merlino, Stefano, Perchiazzi, Natale (2004) Grenmarite, a new member of the gotzenite-seidozerite-rosenbuschite group from the Langesundsfjord district, Norway: definition and crystal structure. European Journal of Mineralogy, 16 (6) 971-978 doi:10.1127/0935-1221/2004/0016-0971 DOI: 10.1127/0935-1221/2004/0016-0971
  3. 2005Bellazza, M. (2005) Crystal-chemical study of Zr,Ti,Nb,REE-disilicates with general formula M16(Si2O7)4(O,OH,F)8, belonging to the cuspidine, gotzenite-rosenbuschite-seidozerite and rinkite families. Plinius, 31. 51-54
  4. 2006Sokolova, E. (2006) From structure topology to chemical composition. I. Structural hierarchy and stereochemistry in titanium disilicate minerals. The Canadian Mineralogist, 44 (6) 1273-1330 doi:10.2113/gscanmin.44.6.1273DOI: 10.2113/gscanmin.44.6.1273
  5. 2014(2014) Grenmarite. Handbook of Mineralogy. Mineralogical Society of America
