Mosandrite-(Ce)

(Ca3REE)[(H2O)2Ca0.50.5]Ti(Si2O7)2(OH)2(H2O)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Msd-Ce
Discovered
1839
Also known as
  • Hydrorinkolit
  • Hydrorinkolita
  • Hydrorinkolite
  • +13 more

Where it forms, where it's found

Type locality
Låven
  1. Larvik Commune
  2. Vestfold
  3. Norway

58.9956°, 9.8175°

55recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Deep reddish brown · brownish green · yellowish · greenish yellow
Streak
Pale yellow, yellowish green
Tenacity
brittle
Cleavage
Distinct/Good

on (100)

Fracture
Irregular/Uneven · Conchoidal
Density
3.2 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 43 – 87° · 2V calc = 62°
Refractive index
1.646 – 1.658
Surface relief
High
Principal indices
nα 1.646 · nβ 1.649 · nγ 1.658
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.398(1) Å · b = 5.595(1) Å · c = 18.662(2) Å
Cell angles
β = 101.37(1) °
Ratio a:b:c
1 : 0.756 : 2.523
Unit cell volume
757.29 ų
Z
2
Morphology

Lath-shaped, prismatic crystals, flattened on (110), elongated along [001]

Comment

Data from Bellezza et al. 2009, Spacegroup is P21/c

Crystal structure

Synonyms

  • Hydrorinkolit
  • Hydrorinkolita
  • Hydrorinkolite
  • Johnstrupit
  • Johnstrupita
  • Lovchorrit
  • Lovchorrita
  • Mosandriet-(Ce)
  • Mosandrita
  • Mosandrite
  • Rincolit
  • Rincolita
  • Rincolite
  • Rinkolit
  • Rinkolita
  • Rinkolite

In other languages

German
2016 s.p. · Mosandrit · Mosandrit-(Ce)
Italian
Mosandrite- · mosandrite-(Ce)
Chinese
褐硅铈矿

Classification

Strunz
10th ed.

9.BE.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.20Mosandrite-(Ce)Species
Dana
8th ed.

56.02.05.01

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.05Mosandrite and related speciesGroup
  • 56.02.05.01Mosandrite-(Ce)Species
CIM

17.1.21

  • 17Silicates Containing other AnionsClass
  • 17.1Silicates with fluoride (not containing Al)Group
  • 17.1.21Mosandrite-(Ce)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. Powder Diffraction File (International Center for Diffraction Data) 45-1422.
  2. 1840Erdmann, Axel (1840) Undersökning af leucophan, ett nytt mineral frän trakten af Brewig i Norrige [Investigation of leucophan, a new mineral from the area of Brewig in Noway]. Kungliga Svenska vetenskapsakademiens handlingar, S. 3 Vol. 28. 191-200
  3. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  4. 1958Fleischer, M. (1958) New Data - Rinkite, Johnstrupite, Rinkolite, Lovchorrite, and Calcium Rinkite (all = Mosandrite). American Mineralogist 43, 795.
  5. 1969Semenov, E. I. (1969): The mineralogy of the Ilimaussaq Alkaline Massif (South Greenland). Nauka, Moscow, Rissia (in Russ.)
