Nacareniobsite-(Ce)

(Ca3REE)Na3Nb(Si2O7)2(OF)F2
IMA status
  • Approved
IMA symbol
Nns-Ce
IMA approved
1987
Also known as
  • IMA1987-040
  • Nacareniobsiet-(Ce)
  • Nacareniobsit
  • +2 more

Where it forms, where it's found

Geological setting

Alkaline igneous complex.

Type locality
Kvanefjeld adit
  1. Kvanefjeld deposit
  2. Kuannersuit Plateau (Kvanefjeld)
  3. Ilímaussaq complex
  4. Kujalleq
  5. Greenland

60.9699°, -45.9929°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless
Cleavage
Distinct/Good

(011)

Fracture
Irregular/Uneven
Density
3.45 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 66° · 2V calc = 68°
Refractive index
1.662 – 1.692
Surface relief
High
Principal indices
nα 1.662 · nβ 1.671 · nγ 1.692
Dispersion
weak
Extinction
X = b; Y ≃ c; γ ∧ a = 11° in the obtuse angle β.
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.4684(15) Å · b = 5.6891(11) Å · c = 18.891(4) Å
Cell angles
β = 101.37(3) °
Ratio a:b:c
1 : 0.762 : 2.529
Unit cell volume
786.9 ų
Z
2
Morphology

Individual ruler-shaped crystals and crystal aggregates; elongate [001], tabular (100), modified by (310) and (410).

Type-locality form

Ruler-shaped crystals up to 3.0 x 0.04 x 0.04 mm, and crystal aggregates.

Comment

former data: P21/a, a=18.901(5), b=5.683(3), c=7.462(2) Å, β=101.29(4) deg.

Crystal structure

Synonyms

  • IMA1987-040
  • Nacareniobsiet-(Ce)
  • Nacareniobsit
  • Nacareniobsita
  • Nacareniobsite

In other languages

German
IMA 1987-040 · Nacareniobsit-(Ce)
Italian
Nacareniobsite- · Nacareniobsite-(Ce)
Portuguese
IMA1987-040 · Nacareniobsita-(Ce)

Classification

Strunz
10th ed.

9.BE.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.20Nacareniobsite-(Ce)Species
Dana
8th ed.

56.02.05.02

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.05Mosandrite and related speciesGroup
  • 56.02.05.02Nacareniobsite-(Ce)Species
CIM

17.8.7

  • 17Silicates Containing other AnionsClass
  • 17.8Silicates with niobate or tantalateGroup
  • 17.8.7Nacareniobsite-(Ce)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1989Petersen, O. V., Rønsbo, J. G., Leonardsen, E. S. (1989) Nacareniobsite-(ce), a new mineral species from the Ilímaussaq alkaline complex, South Greenland, and its relation to mosandrite and the rinkite series. Neues Jahrbuch für Mineralogie - Monatshefte, 1989 (2) 84-96
  2. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
  3. 2008Sokolova, E., Hawthorne, F. C. (2008) From structure topology to chemical composition. V. Titanium silicates: the crystal chemistry of nacareniobsite-(Ce) The Canadian Mineralogist, 46 (5) 1333-1342 doi:10.3749/canmin.46.5.1333 DOI: 10.3749/canmin.46.5.1333
  4. 2013Vilalva, F. C. J., Vlach, S. R. F., Simonetti, A. (2013) Nacareniobsite-(Ce) and britholite-(Ce) in peralkaline granites from the Morro Redondo Complex, Graciosa Province, Southern Brazil: Occurrence and compositional data. The Canadian Mineralogist, 51 (2). 313-332 doi:10.3749/canmin.51.2.313DOI: 10.3749/canmin.51.2.313
  5. 2020(2020) Nacareniobsite-(Ce). Handbook of Mineralogy. Mineralogical Society of America
