Haydeeite

Cu3Mg(OH)6Cl2
IMA status
  • Approved
IMA symbol
Hyd
IMA approved
2006
Also known as
  • Haydeeiet
  • IMA2006-046

Where it forms, where it's found

Geological setting

Underground in a fracture bound copper mine.

Type locality
Haydee Mine
  1. Salar Grande
  2. Iquique
  3. Iquique Province
  4. Tarapacá
  5. Chile

-21.1922°, -69.9906°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Bluish green
Streak
Bright greenish blue
Tenacity
brittle
Cleavage
Perfect

(0001) perfect

Fracture
Irregular/Uneven
Density
3.27 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.71 – 1.753
Surface relief
High
Principal indices
nω 1.753 · nε 1.710
Birefringence
0.043
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0430
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]430 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation430 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#97
Cell parameters
a = 6.2733(4) Å · c = 5.7472(5) Å
Unit cell volume
195.88 ų
Z
1
Morphology

Type material displays the forms (0001), (1010), and (1011).

Twinning

None observed

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper363.546190.638
49.15%
8OOxygenOxygen615.99995.994
24.75%
17ClChlorineChlorine235.45070.900
18.28%
12MgMagnesiumMagnesium124.30524.305
6.26%
1HHydrogenHydrogen61.0086.048
1.56%
Total387.885100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Haydeeiet
  • IMA2006-046

In other languages

German
Haydeeit · IMA 2006-046
Italian
haydeeite

Classification

Strunz
10th ed.

3.DA.10c

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.10cHaydeeiteSpecies
Dana
8th ed.

10.01.02.05

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.01A2(O,OH)3XqType
  • 10.01.02Paratacamite GroupGroup
  • 10.01.02.05HaydeeiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 2007Malcherek, Thomas; Schlüter, Jochen (2007) Cu3MgCl2(OH)6 and the bond-valence parameters of the OH—Cl bond. Acta Crystallographica Section B Structural Science, 63 (1). 157-160 doi:10.1107/s0108768106053870DOI: 10.1107/s0108768106053870
  2. 2007Schlüter, Jochen, Malcherek, Thomas (2007) Haydeeite, Cu3Mg(OH)6Cl2, a new mineral from the Haydee mine, Salar Grande, Atacama desert, Chile. Neues Jahrbuch für Mineralogie - Abhandlungen, 184 (1) 39-43 doi:10.1127/0077-7757/2007/0086DOI: 10.1127/0077-7757/2007/0086
  3. 2008Piilonen, P. C., Poirier, G., Tait, K. T. (2008) New Mineral Names. American Mineralogist, 93 (11) 1941-1946 doi:10.2138/am.2008.531DOI: 10.2138/am.2008.531
  4. 2010Chu, Shaoyan, McQueen, Tyrel M., Chisnell, Robin, Freedman, Danna E., Müller, Peter, Lee, Young S., Nocera, Daniel G. (2010) A Cu2+(S=1/2) Kagomé Antiferromagnet: MgxCu4−x(OH)6Cl2. Journal Of The American Chemical Society, 132 (16) 5570-5571 doi:10.1021/ja1008322DOI: 10.1021/ja1008322
  5. 2011Chu, Shaoyan (2011) Magnetic properties of geometrically frustrated polymorphic crystals of Cu4-xMgx(OH)6Cl2. Journal of Physics: Conference Series, 273. 012123 doi:10.1088/1742-6596/273/1/012123DOI: 10.1088/1742-6596/273/1/012123
