Hochleitnerite

Mn2Ti3(PO4)4O2(H2O)2 · 14H2O
IMA status
  • Approved
IMA symbol
Hln
IMA approved
2023
Also known as
  • Hochleitneriet

Where it forms, where it's found

Geological setting

phosphate pegmatite

Type locality
Hagendorf South Pegmatite
  1. Hagendorf
  2. Waidhaus
  3. Neustadt an der Waldnaab District
  4. Upper Palatinate
  5. Bavaria
  6. Germany

49.6503°, 12.4597°

1recorded occurrences
Source · OpenStreetMap

Physical

Colour
pale yellow
Density
2.40 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 53.8°
Refractive index
1.615 – 1.645
Surface relief
Moderate
Principal indices
nα 1.615 · nβ 1.621 · nγ 1.645
Pleochroism
Non-pleochroic
Notes

2V could not be measured because of the presence of apparent sector zoning, which distorts the conoscopic figure and makes extinction observations unreliable.

Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pbca
Cell parameters
a = 10.5513(3) Å · b = 20.6855(7) Å · c = 12.4575(4) Å
Ratio a:b:c
1 : 1.960 : 1.181
Z
4
Type-locality form

isolated and intergrown pale-yellow, diamond-shaped tablets, up to 50 x 120 µm, "flattened on (010), slightly elongated on [001], and bounded by (111) and (010)" faces

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3415.999543.966
57.05%
22TiTitaniumTitanium347.867143.601
15.06%
15PPhosphorusPhosphorus430.974123.896
12.99%
25MnManganeseManganese254.938109.876
11.52%
1HHydrogenHydrogen321.00832.256
3.38%
Total953.595100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hochleitneriet

In other languages

German
Hochleitnerit · IMA 2022-141
Italian
hochleitnerite · IMA2022-141

Classification

Strunz
10th ed.

8.DH

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DHWith large and medium-sized cations, (OH, etc.):RO4 < 1:1Group
  • 8.DHHochleitneriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2023Grey, Ian E., Keck, Erich, Kampf, Anthony R., MacRae, Colin M., Gable, Robert W., Mumme, William G., Wilson, Nicholas C., Glenn, Alexander M., Davidson, Cameron (2023) Hochleitnerite, [K(H2O)]Mn2(Ti2Fe)(PO4)4O2(H2O)10 ⋅ 4H2O, a new paulkerrite-group mineral, from the Hagendorf-Süd pegmatite, Oberpfalz, Bavaria, Germany. European Journal of Mineralogy, 35 (4) 635-643 doi:10.5194/ejm-35-635-2023 DOI: 10.5194/ejm-35-635-2023
  2. 2023Bosi, Ferdinando, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2023) Newsletter 72. Mineralogical Magazine, 87 (3) 512-518 doi:10.1180/mgm.2023.21DOI: 10.1180/mgm.2023.21
