Wollastonite

CaSiO3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Wo
Also known as
  • Ädelforsit (nach Erdmann)
  • Aedelforsite (of Beudant)
  • Braunstein-Tremolith
  • +22 more

Where it forms, where it's found

Geological setting

In thermally metamorphosed siliceous carbonates, in igneous rocks, and as a skarn deposit.

Type locality
Capo di Bove
  1. Rome
  2. Metropolitan City of Rome Capital
  3. Lazio
  4. Italy

41.8474°, 12.5236°

1,327recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · gray-white · light green · pinkish · brown · red · yellow
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (001) Good on (001) and (102)

Fracture
Irregular/Uneven
Density
2.86 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 36 – 60°
Refractive index
1.616 – 1.653
Surface relief
Moderate
Principal indices
nα 1.616 – 1.640 · nβ 1.628 – 1.650 · nγ 1.631 – 1.653
Dispersion
weak r>v
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.925(3) Å · b = 7.322(1) Å · c = 7.065(1) Å
Cell angles
α = 90.055 ° · β = 95.217 ° · γ = 103.42 °
Ratio a:b:c
1 : 0.924 : 0.891
Z
6
Morphology

Tabular, short or long prismatic. Commonly fibrous, compact, massive.

Twinning

Common, twin axis [010], composition plane (100).

Comment

Cell refers to 1A polytype; several triclinic and monoclinic polytypes are known.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen315.99947.997
41.32%
20CaCalciumCalcium140.07840.078
34.50%
14SiSiliconSilicon128.08528.085
24.18%
Total116.160100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ädelforsit (nach Erdmann)
  • Aedelforsite (of Beudant)
  • Braunstein-Tremolith
  • Brunstens-tremolit
  • Donegalite
  • Gillebachite
  • Gillebäckit
  • Gillebäckita
  • Gillebäckite
  • Gjellebäckite
  • Grammit
  • Grammita
  • Grammite
  • Okenite (of Rink)
  • Parawollastonite
  • Rivait
  • Rivaita
  • Rivaite
  • Tabular Spar
  • Tafelspat (Stütz)
  • Tafelspath (Stütz)
  • Vilnit
  • Vilnita
  • Vilnite
  • Wollastonite (of Léman)

In other languages

French
Gillebachite · Gillebäckite · Gjellebäckite · Grammite · Parawollastonite · Rivaite · Spath en tables · Tafelspath · Vilnite · Wollastonite · Zurlite · Zurlonite
German
CaSiO3 · Parawollastonit · Tafelspat · Tafelspath · Wollastonit · Wollastonit-1A · Wollastonit-1T · Wollastonit-2M · Wollastonit-3A-5A-7A
Spanish
Edelforsita · wollastonita
Italian
wollastonite
Portuguese
wollastonita
Japanese
珪灰石 · 硅灰石
Chinese
矽灰石 · 硅灰石
Russian
Волластонит
Arabic
ولاستونيت

Classification

Strunz
10th ed.

9.DG.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.05WollastoniteSpecies
Dana
8th ed.

65.02.01.1c

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.02Single-Width Unbranched Chains, W=1 with chains P=3Type
  • 65.02.01Wollastonite groupGroup
  • 65.02.01.1cWollastoniteSpecies
CIM

14.5.1

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.1WollastoniteSpecies

Group, growth & confusion

Often grow together
7 minerals
Commonly confused with
5 minerals

Literature, links & citation

Citations
  1. Zeitschrift für Kristallographie: 168: 93-98.
  2. Doklady Akademii Nauk SSSR: 107: 463-466.
  3. Dera, P., Rapp, R., Chornkrathok, S., Zhang, D., Prakapenka, V.B., Woźniak, K. (2023). New high-pressure phase of CaSiO3 wollastonite with penta-coordinated silicon. 9th Meeting of the Mineralogical Society of Poland / 28th Meeting of the Petrology group of the Mineralogical Society of Poland, "Oceanic lithosphere: rocks, minerals, and critical resources", October 19-22, Bielawa, Poland. Mineralogia - Special Papers, 51, 51.
  4. 1802Klaproth, M. H. (1802) CIX. Chemische Untersuchung des Tafelspaths. In Beiträge zur chemischen Kenntniss der Mineralkörper Vol. 3. Rottmann. p.289-291.
  5. 1818Léman, J. (1818) Nouveau Dictionnaire d'Histoire Naturelle.
