Alamosite

PbSiO3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Aam
Discovered
1909
Also known as
  • Alamositt

Where it forms, where it's found

Geological setting

As a rare secondary mineral in the oxidized zone of lead-bearing base metal deposits.

Type locality
Álamos
  1. Álamos Municipality
  2. Sonora
  3. Mexico

27.0167°, -108.9667°

16recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless to white · cream · or light gray
Streak
White
Cleavage
Perfect

(010)

Density
6.488 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 65° · 2V calc = 70°
Refractive index
1.947 – 1.968
Surface relief
Very high
Principal indices
nα 1.947 · nβ 1.961 · nγ 1.968
Dispersion
relatively weak
Michel-Lévy diagramhighlighted lineδ = 0.0210
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]210 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation210 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/m
Cell parameters
a = 12.247 Å · b = 7.059 Å · c = 11.236 Å
Cell angles
β = 113.12 °
Ratio a:b:c
1 : 0.576 : 0.917
Z
12
Morphology

Crystals fibrous parallel [010]; as radiating aggregates and balls, to 7.5 cm.

Type-locality form

Radiating fibrous spheres.

Comment

P2/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
73.14%
8OOxygenOxygen315.99947.997
16.94%
14SiSiliconSilicon128.08528.085
9.92%
Total283.282100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mn
  • Ca

Synonyms

  • Alamositt

In other languages

French
alamosite
German
Alamosit
Spanish
Alamosita
Italian
alamosite
Arabic
ألاموسيت

Classification

Strunz
10th ed.

9.DO.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DOInosilicates with 7-, 8-, 10-, 12- and 14-periodic chainsGroup
  • 9.DO.20AlamositeSpecies
Dana
8th ed.

65.07.01.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.07Single-Width Unbranched Chains, W=1 with chains P > 7Type
  • 65.07.01— unnamed intermediate level —Group
  • 65.07.01.01AlamositeSpecies
CIM

14.13.1

  • 14Silicates not Containing AluminumClass
  • 14.13Silicates of PbGroup
  • 14.13.1AlamositeSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1909Palache, C., Merwin, Η. E. (1909) Alamosit, ein neues Bleisilicat aus Mexico. Zeitschrift für Kristallographie, 46 (1). 513-515 doi:10.1524/zkri.1909.46.1.513DOI: 10.1524/zkri.1909.46.1.513
  2. 1909Palache, C., Merwin, H.E. (1909) Alamosite, a new lead silicate from Mexico. American Journal of Science: 27: 399-401.
  3. 1952Mackay, A. L. (1952) The unit cell and space-group of alamosite (PbSiO3) Mineralogical Magazine and Journal of the Mineralogical Society, 29 (218) 933-935 doi:10.1180/minmag.1952.029.218.05 DOI: 10.1180/minmag.1952.029.218.05
  4. 1968Boucher, M. L., Peacor, Donald R. (1968) The crystal structure of alamosite, PbSiO3. Zeitschrift für Kristallographie, 126 (1). 98-111 doi:10.1524/zkri.1968.126.1-3.98 DOI: 10.1524/zkri.1968.126.1-3.98
  5. 1975Medenbach, O. and Schmetzer, K. (1975). Alamosit (PbSiO3) von Tsumeb – ein neuer Fundpunkt [Alamosite (PbSiO3) from Tsumeb – a new occurrence]. Neues Jahrbuch für Mineralogie, Abhandlungen, 123 (2), 138-147.
