Fluor-uvite

CaMg3(Al5Mg)(Si6O18)(BO3)3(OH)3F
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fluvt
Discovered
1929
IMA approved
2010
Also known as
  • Fluor-uviet

Where it forms, where it's found

Geological setting

Calcium-rich rocks subjected to contact metamorphism and addition of boron.

Type locality
Franklin
  1. Sussex County
  2. New Jersey
  3. USA

41.1219°, -74.5808°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Black · greenish-black · brownish-black · brown · green · colourless
Streak
Light-brown, light-green, or white
Tenacity
brittle
Cleavage
None Observed
Density
2.97 g/cm³

Optical

Optical type
Uniaxial
Refractive index
1.619 – 1.668
Surface relief
Moderate
Principal indices
nω 1.637 – 1.668 · nε 1.619 – 1.639
Pleochroism
Weak

O= pale yellow E= colorless

UV response
May show a weak mustard-yellow under SW
Michel-Lévy diagramhighlighted lineδ = 0.0235
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]235 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation235 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.954(1) Å · c = 7.214(1) Å
Z
3
Morphology

Prismatic to equant crystals, tabular, pyramidal, radiating groups.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
49.22%
14SiSiliconSilicon628.085168.510
17.28%
13AlAluminiumAluminium526.982134.910
13.83%
12MgMagnesiumMagnesium424.30597.220
9.97%
20CaCalciumCalcium140.07840.078
4.11%
5BBoronBoron310.81032.430
3.33%
9FFluorineFluorine118.99818.998
1.95%
1HHydrogenHydrogen31.0083.024
0.31%
Total975.140100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Ti
  • Na
  • Cr
  • V
  • Zn
  • H2O

Synonyms

  • Fluor-uviet

In other languages

French
Fluor-uvite · uvite
German
Fluor-Uvit
Spanish
uvita
Italian
uvite

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05Fluor-uviteSpecies
Dana
8th ed.

61.03.01.03

  • 61Cyclosilicates Six-membered RingsClass
  • 61.03Six-Membered Rings with borate groupsType
  • 61.03.01— unnamed intermediate level —Group
  • 61.03.01.03Fluor-uviteSpecies

Group, growth & confusion

Often grow together
3 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1977Nelen, Joseph A., Dunn, Pete J., Appleman, Daniel, Norberg, Julie (1977) Uvite, a New (Old) Common Member of the Tourmaline Group and Its Implications for Collectors. The Mineralogical Record, 8 (2) 100-108
  2. 2007Rozhdestvenskaya, I. V., Frank-Kamenetskaya, O. V., Kuznetsova, L. G., Bannova, I. I., Bronzova, Yu. M. (2007) Refinement of the crystal structure of lithium-bearing uvite. Crystallography Reports, 52 (2). 203-207 doi:10.1134/s106377450702006xDOI: 10.1134/s106377450702006x
  3. 2011Henry, Darell J., Novak, Milan, Hawthorne, Frank C., Ertl, Andreas, Dutrow, Barbara L., Uher, Pavel, Pezzotta, Federico (2011) Nomenclature of the tourmaline-supergroup minerals. American Mineralogist, 96 (5) 895-913 doi:10.2138/am.2011.3636 DOI: 10.2138/am.2011.3636
  4. 2014Fantini, C., Tavares, M. C., Krambrock, K., Moreira, R. L., Righi, A. (2014) Raman and infrared study of hydroxyl sites in natural uvite, fluor-uvite, magnesio-foitite, dravite and elbaite tourmalines. Physics and Chemistry of Minerals, 41 (4) 247-254 doi:10.1007/s00269-013-0642-0DOI: 10.1007/s00269-013-0642-0
  5. 2024Bačík, Peter, Kardošová, Petra, Fridrichová, Jana, Rybnikova, Olena, Škoda, Radek (2024) Crystal-chemical effects of heat treatment on Cr- and V-bearing Ca-dominant green tourmalines (fluor-uvite, magnesio-lucchesiite). Periodico di Mineralogia, 93 (3). 147-164 doi:10.13133/2239-1002/18524 DOI: 10.13133/2239-1002/18524
