Ushkovite

MgFe3+2(PO4)2(OH)2 · 8H2O
IMA status
  • Approved
IMA symbol
Ukv
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-014
  • Ushkoviet

Where it forms, where it's found

Geological setting

Granite pegmatite

Late stage mineralization in granite pegmatites

Type locality
Pit No. 232
  1. Bol'shoi Tatkul' Lake
  2. Argayashsky District
  3. Chelyabinsk Oblast
  4. Russia
20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Pearly · Greasy
Transparency
Transparent · Translucent
Colour
Pale yellow · orange-yellow · orange · orange brown
Streak
Pale yellow
Tenacity
very brittle
Cleavage
Perfect

(010)

Density
2.38 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 50° · 2V calc = 74°
Refractive index
1.584 – 1.67
Surface relief
Moderate
Principal indices
nα 1.584 · nβ 1.637 · nγ 1.670
Birefringence
0.084
Pleochroism
Non-pleochroic
Dispersion
small
Extinction
Y^c = 26°, X, Y in {010}
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0840
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]840 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation840 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.3468(4) Å · b = 10.592(1) Å · c = 7.2251(7) Å
Cell angles
α = 108.278(7) ° · β = 111.739(7) ° · γ = 71.626(7) °
Ratio a:b:c
1 : 1.981 : 1.351
Z
2
Morphology

Usually simple, striated pinacoidal crystals, rarely with modifying faces

Twinning

On {hk0}.

Type-locality form

Small orange short lath-like crystals

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
57.13%
26FeIronIron255.845111.690
22.16%
15PPhosphorusPhosphorus230.97461.948
12.29%
12MgMagnesiumMagnesium124.30524.305
4.82%
1HHydrogenHydrogen181.00818.144
3.60%
Total504.069100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-014
  • Ushkoviet

In other languages

German
IMA 1982-014 · Ushkovit
Italian
Ushkovite

Classification

Strunz
10th ed.

8.DC.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.30UshkoviteSpecies
Dana
8th ed.

42.11.10.04

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.10Laueite GroupGroup
  • 42.11.10.04UshkoviteSpecies
CIM

19.14.11

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.11UshkoviteSpecies

Group, growth & confusion

Often grow together
6 minerals
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1983Chesnokov, B.V., Vilisov, V.A., Cherepivskaya, G.E., Gorskaya, M.G. (1983) Ushkovite, MgFe3+2(PO4)2(OH)2·8H2O. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 112(1): 42-46.
  2. 1984Dunn, Pete J., Grice, Joel D. Fleischer, Michael, Pabst, Adolf (1984) New mineral names. American Mineralogist, 69 (1-2) 210-215
  3. 2002Galliski, M. A., Hawthorne, F. C. (2002) Refinement of the crystal structure of ushkovite from Nevados de Palermo, Republica Argentina. The Canadian Mineralogist, 40 (3) 929-937 doi:10.2113/gscanmin.40.3.929 DOI: 10.2113/gscanmin.40.3.929
  4. 2005(2005) Ushkovite. Handbook of Mineralogy. Mineralogical Society of America
