Paratacamite-(Ni)

Cu3(Ni,Cu)Cl2(OH)6
IMA status
  • Approved
IMA symbol
Pata-Ni
IMA approved
2013
Also known as
  • IMA2013-013
  • Paratacamiet-(Ni)

Where it forms, where it's found

Geological setting

Oxidation zone of a nickel sulfide deposit

Type locality
Carr Boyd Rocks Ni mine
  1. Menangina Station
  2. Menzies Shire
  3. Western Australia
  4. Australia

-30.0668°, 121.6269°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark green
Streak
Light green
Tenacity
brittle
Cleavage
Distinct/Good

(1011)

Fracture
Irregular/Uneven
Density
3.70 g/cm³

Optical

Optical type
Uniaxial (-)
Principal indices
nω >1.8 · nε >1.8
Pleochroism
Non-pleochroic
UV response
none
Notes

Refractive indices greater than 1.80, but mineral reacts with RI fluids. Average is 1.81 from Gladstone Dale calculation.

Michel-Lévy diagramhighlighted lineδ = 0.0000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]0 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation0 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#80
Cell parameters
a = 13.682(2) Å · c = 13.916(2) Å
Parting
None
Type-locality form

aggregates up to 2 mm in size of equant, rhombohedral crystals showing the forms (101), (021) and (001).

Comment

Space group by analogy to paratacamite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper463.546254.184
52.32%
8OOxygenOxygen615.99995.994
19.76%
17ClChlorineChlorine235.45070.900
14.59%
28NiNickelNickel158.69358.693
12.08%
1HHydrogenHydrogen61.0086.048
1.25%
Total485.819100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • (Co)

Synonyms

  • IMA2013-013
  • Paratacamiet-(Ni)

In other languages

German
IMA 2013-013 · Paratacamit-(Ni)
Italian
paratacamite-(Ni)

Classification

Strunz
10th ed.

3.DA.10c

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.10cParatacamite-(Ni)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2013Sciberras, Matthew J., Leverett, Peter, Williams, Peter A., Hibbs, David E., Downes, Peter J., Welch, Mark D., Kampf, Anthony R. (2013) Paratacamite-(Ni): Cu3(Ni,Cu)Cl2(OH)6, a new mineral from the Carr Boyd Rocks mine, Western Australia. Australian Journal of Mineralogy,, 17. 39-44
  2. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) New minerals and nomenclature modifications approved in 2013. CNMNC Newsletter No 16. Mineralogical Magazine, 77 (6) 2695-2709 doi:10.1180/minmag.2013.077.6.01DOI: 10.1180/minmag.2013.077.6.01
  3. 2016(2016) Paratacamite-(Ni). Handbook of Mineralogy. Mineralogical Society of America
