Osumilite

KFe2(Al5Si10)O30
IMA status
  • Approved
  • Grandfathered
IMA symbol
Osm
Discovered
1953
Also known as
  • Osumilite-(Fe)

Where it forms, where it's found

Geological setting

Biotite-bearing hypersthene-plagioliparite (rhyodacite).

Type locality
Sakkabira
  1. Kagoshima Prefecture
  2. Japan

31.5856°, 130.6522°

29recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Black · dark blue · dark brown · pink · gray

Strongly pleochroic

Tenacity
brittle
Cleavage
Poor/Indistinct

Indistinct, parallel and perpendicular (0001)

Density
2.58 g/cm³

Optical

Optical type
Uniaxial (+/-) · 2V measured = 28 – 45° · 2V calc = 0.0°
Refractive index
1.539 – 1.551
Surface relief
Moderate
Principal indices
nω 1.539 – 1.547 · nε 1.545 – 1.551
Pleochroism
Visible

O = light blue to bluish purple, pale pink, pale yellow-brown; E = colorless to brown.

Extinction
Nominally uniaxial(+/-), but may be anomalously biaxial (+/-) with a 2V° from 0 (so true uniaxial) up to ~45°.
Notes

Anomalously biaxial.

Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P6/mcc
Cell parameters
a = 10.13(4) Å · c = 14.31(5) Å
Z
2
Morphology

Hexagonal, tabular. Well developed (0001), (1010), (1120). Also (2130), (1011), (1012), (1122).

Twinning

Rarely, perpendicular to (0001).

Type-locality form

In crystals, a few millimeters or less in size, black to the unaided eye, and prismatic or tabular in habit. Previously mistaken for cordierite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
45.86%
14SiSiliconSilicon1028.085280.850
26.84%
13AlAluminiumAluminium526.982134.910
12.89%
26FeIronIron255.845111.690
10.67%
19KPotassiumPotassium139.09839.098
3.74%
Total1046.518100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • Ba
  • Na
  • Mg

Synonyms

  • Osumilite-(Fe)

In other languages

German
Osumilith
Spanish
Osumilita · Osumilita-(Fe)
Italian
osumilite
Japanese
大隅石

Classification

Strunz
10th ed.

9.CM.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CM[Si6O18]12- 6-membered double rings (sechser-Doppelringe)Group
  • 9.CM.05OsumiliteSpecies
Dana
8th ed.

63.02.1a.06

  • 63Cyclosilicates Condensed RingsClass
  • 63.02Condensed Rings (Milarite - Osumilite group)Type
  • 63.02.1a— unnamed intermediate level —Group
  • 63.02.1a.06OsumiliteSpecies
CIM

16.24.16

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.24Aluminosilicates of Fe, Mg, Ca and alkalisGroup
  • 16.24.16OsumiliteSpecies

Group, growth & confusion

Often grow together
7 minerals

Literature, links & citation

Citations
  1. 1948Morimoto, R. (1948) On the modes of occurrence of cordierite from Sakkabira, Town Tarumizu, Kimotsuki Province, Kagoshima Prefecture, Japan. Bulletin of the Earthquake Research Institute, 25, 33-35. (as cordierite)
  2. 1949Morimoto, R., Minato, H. (1949) Occurrence of cordierite from Sakkabira, Taru-mizu, Kagoshima Prefecture Journal of the Japanese Association of Mineralogists, Petrologists and Economic Geologists, 33, 51-61. (as cordierite)
  3. 1953Miyashiro, A (1953) Osumilite, a New Mineral, and Cordierite in Volcanic Rocks. Proceedings of the Japan Academy, 29 (7) 321-323 doi:10.2183/pjab1945.29.321DOI: 10.2183/pjab1945.29.321
  4. 1956Miyashiro, Akiho (1956) Osumilite, a new silicate mineral and its crystal structure. American Mineralogist, 41 (1-2) 104-116
  5. 1969Brown, G. E., Gibbs, G. V. (1969) Refinement of the crystal structure of osumilite. American Mineralogist, 54 (1-2) 101-116
